TH 82 Caterpillar Telehandler Specs & Dimensions (1996 - 2002)

Versatility

Cat Telehandlers are designed to perform in a wide range of applications. Features such as a hydraulic quick coupler, low boom profile, and ample work tool rotation make it an extremely versatile machine. The hydraulic quick coupler allows operators to effortlessly couple the right work for the job. Additionally, the ample work tool rotation enables the machine to shine in bucket applications.

Hydraulic Quick Coupler

All Caterpillar Telehandlers use a hydraulic quick coupler for fastening work tools to the front of the boom. This easy-to-use attachment point allows the use of a wide range of work tools, taking advantage of the standard auxiliary hydraulic supply and the ample boom head rotation. Work tools hook over the top of the coupler and are secured by two hydraulically engaged pins at the bottom.

Work Tools

A wide range of work tools are available to meet most job site applications. Lift and place operations are easily accomplished with a wide variety of carriages and forks. An assortment of buckets and hydraulically assisted work tools are also available. Caterpillar Telehandler Work Tools expand the versatility of the machine. Built for performance and durability, these work tools deliver high productivity, long life, and excellent value:General Purpose Bucket (1.0 m³)Grapple Bucket (0.85 m³)Light Material Bucket (2.0, 2.5 and 3.0 m³)Material Handling Bucket (1.5 m³)Multi Purpose Bucket (1.0 m³)Fixed CarriagesRotate CarriagesBlock ForksPallet ForksLifting HookSelf Tipping HopperTruss BoomBale HandlerManure ForksManure Forks and GrabManure Forks, Grab and push-off deviceAccess Platform

Axial-piston hydraulic pump

The hydraulic pump automatically adjusts to meet the constantly changing requirements for optimum performance and fuel efficiency. The pump has been sized for maximum productivity.

Engine

Caterpillar four-stroke cycle, four cylinder 3054 T turbocharged diesel engine. Net power advertised is the power available at the flywheel when the engine is equipped with fan, air cleaner, muffler and alternator. The Caterpillar 3054 T meets current European emission regulations. Direct-injection, rotary fuel pump with individual, adjustment-free injection valves. Cast-iron block with internally stiffened deep skirt design. Replaceable valve guides and seats. Large-diameter, hardened chrome-molybdenum steel crankshaft. Three-ring, controlled-expansion pistons lubricated from oil jets. Helical steel front gear train. Fuel priming pump and fuel/water separator are standard. Gear-driven water pump. 12-volt negative ground, 950 CCA maintenance-free battery and 55-amp alternator. Enclosed, positive-engagement starter. Thermal starting aid. Dual-element, two-stage air cleaner. Filter restriction indicator. Vertical exhaust.

Low Boom Design

The machine’s low profile design allows for loads to be carried with the boom in a low position. Carrying loads in this position improves visibility to the front and right side of the machine. Low boom design provides unobstructed visibility when in the load carry position. For maximum visibility, load must be carried as low as possible. Flexible, close-fitting fenders resist damage, while protecting the operator and machine components from jobsite debris. Fenders move with the wheels, allowing the operator to easily determine wheel direction. The carefully profiled engine hood enhances visibility and allows for easy access to the engine compartment.

Powershift Transmission

Standard on all machines. The twist grip control allows operators to easily select machine direction and transmission speed.

Frame Leveling

The three position, frame leveling switch is used to level the machine when on uneven surfaces. The machine allows a maximum tilt of 10° to either side.

Serviceability

Cost of operation starts with ease of service. All Cat Telehandler service points are readily accessible and major components are easy to reach at ground level due to overall machine design.

Outstanding load control

The Cat Telehandler’s load sensing hydraulic system provides smooth power on demand, allowing the operator to efficiently place loads.

Compensated control valve

The pressure and flow compensated control valve provides load independent flow distribution for exceptional control, modulation and multi-function capability.

Single, multi-function joystick

All boom and auxiliary functions are controlled with a single, smooth operating ergonomic joystick. The pilot-operated joystick allows remote location of the main hydraulic control valve and other hydraulic components. This reduces operator fatigue, exposure to noise, vibration and excess heat.

Load Charts

Conveniently located in front of the operator. Load charts define the operating range and weight in which a load can be lifted and placed.

Features

Three steering modes: Circle steer Two-wheel steer Crab steer Tight outside turning radius Dash-mounted switch for selecting steering modes Lighted steering mode indicator on dash.

Panoramic View

The ergonomically designed operator station provides excellent all-around visibility. The adjustable suspension seat accommodates a wide range of operators, allowing optimal adjustment in the settings.

Suspension Seat

Ergonomically designed for comfort in hardworking environments. The fully adjustable suspension seat is also designed to accommodate various operator requirements. (Optional cloth seat shown).

Instrument Cluster

Gauges are designed to help operators monitor machine operating conditions. The gauge cluster includes an Hour meter, Transmission and Coolant temperature gauges, and Fuel Level indicator.
