3707 PS JLG Telehandler Specs & Dimensions (2013 - 2017)

Name: JLG 3707 PS Telehandlers
Brand: JLG

The JLG 3707 PS telehandler, manufactured from 2013 to 2017, has a weight of 8.3 tons and a transport length of 5.15 meters. It ha…

The JLG 3707 PS telehandler, manufactured from 2013 to 2017, has a weight of 8.3 tons and a transport length of 5.15 meters. It has a nominal load at the center of gravity of 3.7 tons and a lifting height of 7.3 meters. The telehandler has a capacity of 1.5 tons at full forward reach and at full lift height. It has a center of gravity at 500 millimeters. The transport width and height are both 2.38 meters. The telehandler is equipped with StVZO equipment.

3707 PS

Years of manufacture: 2013—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 3707 PS JLG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 3.7 t

Model series: PS

Centre of gravity: 500 mm

Standard tyres: 400/80-24

Transmission type: W

Max. Reach horizontal: 3.8 m

Capacity at full forward reach: 1.5 t

Lifting height: 7.3 m

Capacity at full lift height: 1.5 t

Weight: 8.3 t

Transport length: 5.15 m

Transport width: 2.38 m

Transport height: 2.38 m

Travel speed: 40 km/h

max. climbing ability: 51 %

Engine manuf.: Deutz

Engine type: TCD3.6 L4

Engine power: 74 kW

Displacement: 3.6 l

Revolutions at max torque: 1600 rpm

No. of cylinders: 4

Emission level: V/Tier 4 f

More technical details, like: drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, max. torque, cylinder bore x stroke, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, telematics available, engine manufacturer, engine model, emission rating, aspiration, engine output - gross, torque, tyre - front size, tyre 2 - front size option, service brake - type, service brake - location, dimension configuration, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, boom angle - maximum, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, turning radius - over tyres, breakout force, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, raise time - boom, extend time - boom, speed - forward maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter: No
StVZO Equipment: Yes
Inclination correction: No
Side displacement: No
