TLT30D JCB Telehandler Specs & Dimensions (2017 - 2022)

Name: JCB TLT30D Telehandlers
Brand: JCB

The JCB TLT30D is a telehandler manufactured by JCB from 2017 to 2022. It weighs 5.1 tons and has a maximum horizontal reach of 2…

The JCB TLT30D is a telehandler manufactured by JCB from 2017 to 2022. It weighs 5.1 tons and has a maximum horizontal reach of 2.39 meters. The nominal load at the center of gravity is 3 tons, and it can lift up to a height of 4 meters. At full forward reach, it has a capacity of 1.25 tons, and at full lift height, it can handle 2.75 tons. The center of gravity is located at 500 mm. It has a maximum climbing ability of 30 percent and can travel at a speed of 20 km/h with or without a load.

TLT30D

Years of manufacture: 2017—2022

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - TLT30D JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 3 t

Model series: TLT

Centre of gravity: 500 mm

Standard tyres: 4x/2

Transmission type: HY

Max. Reach horizontal: 2.39 m

Capacity at full forward reach: 1.25 t

Lifting height: 4 m

Capacity at full lift height: 2.75 t

Weight: 5.1 t

max. climbing ability: 30 %

Travel speed with / without load: 20 km/h

Engine manuf.: Perkins

Engine type: k.A.

Engine power: 37 kW

More technical details, like: transport length, transport width, transport height, travel speed, drive system, voltage, traction motor, hoist motor, hoisting with / without load, lowering with load, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter: No
StVZO Equipment: No
Inclination correction: No
Side displacement: No
