    Bobcat T 2556 Specifications & Technical Data (2000-2003)

    Rate this machine now!

    Bobcat is the manufacturer of the telehandler model T 2556. Find and download detailed specs and data sheets for this machine here... Read more

    Bobcat is the manufacturer of the telehandler model T 2556. Find and download detailed specs and data sheets for this machine here.

    Equipped with a powerful Perkins engine, this T 2556 4.92t machine can provide 60kW or 80 horse power for the telehandler. The Bobcat T 2556 can be grouped in the smallest machine segment in the telehandlers category. The model's dimensions are 4.408m x 1.984m x 2.096m. 400/70x20 is the size of standard tyres equipped on this Bobcat T 2556 telehandler. The Telehandler T 2556 Bobcat is designed to travel at a top speed of 30km/h. Max. Horizontal reach of this T 2556 model from Bobcat is 3,05m. With a center of gravity of 500mm, this model can lift a nominal load of 2.5t. The Bobcat T 2556 can lift 2.5t at a full lift height of 5.56m. The Bobcat T 2556 can operate up to 1.1t at full forward reach.

    StVZO Equipment, Side displacement and Diesel particulate filter are not provided on this model as of 2003. There are more detailed specifications and machine descriptions available in the original Bobcat T 2556 specs data sheet. You can download it for free in German on LECTURA Specs.

    This model can be acquired for a list price between €47,000 and €59,000. Production of the T 2556 stopped in 2003. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    Based on other telehandlers specifications and pricing variations, the Bobcat T 2556 can be considered similar to the Sambron T 2555, Massey Ferguson MF 8925 and Claas 907. Bobcat currently produces 37 other telehandlers, which range from 2.6t up to 4.1t - the most visited on LECTURA Specs are T40180 IIIB, TL470 Agri, TL470HF Agri. Want more detailed specifications? Download the latest Bobcat T 2556 specs data sheet on LECTURA Specs today!

    Total Cost of Ownership for 3-4t Telehandlers

    BUY (Annual Ownership Cost): 16 730.79 € RENTAL COST (Annual Rental Cost): 15 521.03 €.

    Customize the calculation *Presented prices are sample calculations.

    Provided by

    Technical specs - T 2556 Bobcat

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Nominal load at COG 2.5 t
    Standard tyres 400/70x20
    Centre of gravity 500 mm
    Transmission type HY
    Max. Reach horizontal 3,05 m
    Capacity at full forward reach 1.1 t
    Lifting height 5.56 m
    Capacity at full lift hight 2.5 t
    Weight 4.92 t
    Transport length 4.408 m
    Transport width 1.984 m
    Transport height 2.096 m
    Travel speed 30 km/h
    Engine manuf. Perkins
    Engine type 1004.42
    Engine power 60 kW
    max. climbing ability ###
    Engine power ###
    Dimension lxwxh ###
    Displacement ###
    Revolutions at max torque ###
    Max. torque ###
    No. of cylinders ###
    Cylinder bore x stroke ###
    Weight ###
    Emission level ###
    Cab Position ###
    Chassis Type ###
    Levelling - Chassis ###
    Stabilisers ###
    Drive - 2W / 4W ###
    Transmission Type ###
    Engine Manufacturer ###
    Engine Model ###
    Aspiration ###
    Rated Speed ###
    Engine Output - Net ###
    Tyre - Front Size ###
    Tyre - Rear Size ###
    Tyre 2 - Front Size Option ###
    Tyre 2 - Rear Size Option ###
    Service Brake - Type ###
    Service Brake - Location ###
    Length - Front Of Carriage ###
    Height - Over Cab ###
    Width - Operating ###
    Wheelbase ###
    Ground Clearance ###
    Width - Cab ###
    Lift Height - Maximum ###
    Reach - Maximum ###
    Unstabilised Lift Height - With Maximum Capacity ###
    Turning Radius - Over Tyres ###
    Breakout Force ###
    Lift Capacity - Maximum ###
    Lift Capacity - To Max Height ###
    Lift Capacity - To Max Reach ###
    Unstabilised Lift Capacity - Maximum ###
    Unstabilised Lift Capacity - To Max Height ###
    Unstabilised Lift Capacity - To Max Reach ###
    Fuel Tank ###
    Number Of Boom Sections ###
    Load Centre ###
    Lift Capacity - Fork Maximum ###
    Raise Time - Boom ###
    Extend Time - Boom ###
    Speed - Forward Maximum ###
    Operating Weight ###

    All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

    T 2556 Bobcat - Special equipment

    • Diesel particulate filter
    • StVZO Equipment
    • Inclination correction
    • Side displacement
