Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
| Nominal load at COG | 1.814 t |
|---|---|
| Standard tyres | Front: 21 x 7 x 15 / Rear: 16 x 6 x 10.5 |
| Centre of gravity | 610 mm |
| Weight | 3.955 t |
| Total width | 1090 mm |
| Construction height | 2108 mm |
| Turning radius | 1.991 m |
| Lifting height | 7.467 m |
| Travel speed with / without load | 17.5 / 17.7 km/h |
| Hoisting with / without load | 0.65 / 0.66 m/s |
| Lowering with load | 0.47 m/s |
| max. climbing ability | 34.1 % |
| Engine manuf. | N/A |
| Engine type | N/A |
| Engine power | 44 kW |
| Engine power | 59 HP |
| Displacement | 2.4 l |
| Revolutions at max torque | 1400 rpm |
| Max. torque | 169.4 Nm |
| No. of cylinders | 4 |
| Transmission type | ### |
| Dimension lxwxh | ### |
| Cylinder bore x stroke | ### |
| Weight | ### |
| Emission level | ### |
L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
