GC40K Caterpillar LPG Forklift Specs & Dimensions (2019 - 2026)

Name: Caterpillar GC40K LPG Forklifts
Brand: Caterpillar

Nominal load at COG: 4t – Centre of gravity: 500mm – Standard tyres: Front: 22x9x16 / Rear: 18x7x12.1 – Weight: 5.57t – Total widt…

Nominal load at COG: 4t – Centre of gravity: 500mm – Standard tyres: Front: 22x9x16 / Rear: 18x7x12.1 – Weight: 5.57t – Total width: 1180mm – Construction height: 2120mm

Caterpillar is the manufacturer of the GC40K LPG forklift. The production years for this model are (2019 - 2026). Find here detailed specs for GC40K LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Caterpillar.

GC40K

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - GC40K Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 4 t

Centre of gravity: 500 mm

Standard tyres: Front: 22x9x16 / Rear: 18x7x12.1

Weight: 5.57 t

Total width: 1180 mm

Construction height: 2120 mm

Turning radius: 2.285 m

Lifting height: 3.05 m

Travel speed with / without load: 19.0/19.5 km/h

Hoisting with / without load: 0.54/0.57 m/s

Lowering with load: 0.55 m/s

max. climbing ability: 33 %

Model series: GC

Engine manuf.: N/A

Engine type: PSI 4X

Engine power: 78 kW

Revolutions at max torque: 1000 rpm

Max. torque: 285 Nm

No. of cylinders: 6

More technical details, like: transmission type, dimension lxwxh, displacement, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Download specalog and datasheets (PDF)

Caterpillar GC40K overview

Handling

Lower Cost of Ownership

Informative display panel reduces costly, unscheduled downtime. Easy to access engine allows for quick, easy inspection and maintenance. Rugged mast offers good visibility, while tapered fork bars allow good visibility through the carriage. Hydraulic cushioning on Triplex masts reduces the risk of load damage.

Performance

Unmatched Productivity

Powered by a proven engine giving smooth, quiet performance and high torque at low speeds - essential for handling heavy loads. Electronically-controlled VORTEC induction system optimizes fuel and air mixture to give efficient low-end power. Short wheelbase and a small turning radius give good maneuverability. STR models feature extra-heavy counterweights, which permit a short turning radius, providing greater maneuverability and rearward visibility. Additionally, a vacuum-boosted brake system ensures easy operation. The 3.5 - 5.5 tonne models feature a single speed power shift transmission, while the 6.0 - 7.0 tonne models are equipped with a two-speed automatic transmission.

Safety

Options

Speed limit options Foot directional control Double element cyclone air cleaner Non marking tires Dust proof kit for hydraulic tank and pump Rear view mirror

Cabin & Equipment

Safety & Ergonomics

An open-step frame and easy-to-reach grab bar allow easy entry and exit. Noise reduction and vibration damping reduce operator fatigue. An adjustable, full suspension seat enhances operator comfort by resisting shock and vibration from rough and uneven surfaces. Additionally, the adjustable tilt steering column improves operator comfort. The hydraulic controls allow precise, short-throw operation, while the seat-activated transmission interlock system disengages the drive function if the operator leaves the seat.
