MV 25 BVT Belet LPG Forklift Specs & Dimensions (2013 - 2024)

Nominal load at COG: 2.5t – Centre of gravity: 500mm – Standard tyres: L4 – Transmission type: W – Weight: 3.808t – Total width: 1…

Nominal load at COG: 2.5t – Centre of gravity: 500mm – Standard tyres: L4 – Transmission type: W – Weight: 3.808t – Total width: 1160mm

Belet is the manufacturer of the MV 25 BVT LPG forklift. The production years for this model are (2013 - 2024). Find here detailed specs for MV 25 BVT LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Belet.

LPG Forklifts Belet MV 25 BVT

Technical specs - MV 25 BVT Belet

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
2.5 t
Centre of gravity
500 mm
Standard tyres
L4
Transmission type
W
Weight
3.808 t
Total width
1160 mm
Construction height
2195 mm
Turning radius
2.23 m
Lifting height
3.3 m
Travel speed with / without load
18/16 km/h
Hoisting with / without load
0.625/0.603 m/s
max. climbing ability
23 %
Model series
MV
Engine manuf.
Nissan
Engine type
K21
Engine power
32 kW
Displacement
2.065 l
Revolutions at max torque
3200 rpm
No. of cylinders
4

More technical details, like: lowering with load, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
