Baoli KBG 35+ EU5
- Nominal load at COG:
- 3.5 t
- Centre of gravity:
- 500 mm
- Transmission type:
- W
- Weight:
- 4.96 t
KBG 35+ EU5 Baoli LPG Forklift Specs & Dimensions (2021 - 2026)
Technical specs - KBG 35+ EU5 Baoli
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal load at COG
- 3.5 t
- Centre of gravity
- 500 mm
- Transmission type
- W
- Weight
- 4.96 t
- Total width
- 1285 mm
- Construction height
- 2110 mm
- Turning radius
- 2.54 m
- Lifting height
- 3 m
- Travel speed with / without load
- 17/17 km/h
- Hoisting with / without load
- 0.46/0.55 m/s
- Lowering with load
- 0.48 m/s
- max. climbing ability
- 20 %
- Model series
- KBG
- Engine manuf.
- Doosan
- Engine type
- P24
- Engine power
- 40.2 kW
- Displacement
- 2.4 l
- No. of cylinders
- 4
- Emission level
- Euro 5
More technical details, like: standard tyres, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
