YCH08 Yuchai YCH08 Specifications & Technical Data (2017—2026)

The Yuchai YCH08 is a skid steer loader manufactured since 2017. It has a weight of 2.85 tons and a transport length of 3.3 meters…

The Yuchai YCH08 is a skid steer loader manufactured since 2017. It has a weight of 2.85 tons and a transport length of 3.3 meters. The bucket capacity is 0.43 cubic meters, and it can reach a maximum discharge height of 2.3 meters. The transport width is 1.68 meters, and the transport height is 2.01 meters. It has a rated operating capacity of 800 kilograms.

Skid Steer Loaders Yuchai YCH08

Technical specs - YCH08 Yuchai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.85 t
Rated operating capacity
800 kg
Standard tyres
10-16.5（L-2B）
Bucket capacity
0.43 m³
Driver protection
KbR
Transport length
3.3 m
Transport width
1.68 m
Transport height
2.01 m
Max. discharge height
2.3 m
Engine manuf.
Kubota
Engine type
2403M-T-E3B
Engine power
41.7 kW
Displacement
2.434 l
Revolutions at max torque
1800 rpm
Max. torque
163.7 Nm
Cylinder bore x stroke
87x102.4 mm

More technical details, like: track width, bucket width, steering mode, travel speed, lifting force, model series, dimension lxwxh, no. of cylinders, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Yuchai YCH08 FAQ

When was the Yuchai YCH08 skid steer loader manufactured?

The Yuchai YCH08 skid steer loader was first produced in 2017.

How much does the Yuchai YCH08 skid steer loader weigh?

The Yuchai YCH08 skid steer loader weighs 2.85 tons.

What are the transport dimensions of the Yuchai YCH08 skid steer loader?

The Yuchai YCH08 has a transport length of 3.3 meters, a transport width of 1.68 meters, and a transport height of 2.01 meters.

What are the undercarriage specifications of the Yuchai YCH08 skid steer loader?

The Yuchai YCH08 skid steer loader is equipped with standard tyres sized 10-16.5 (L-2B).

What is the material handling capacity of the Yuchai YCH08 skid steer loader?

The Yuchai YCH08 skid steer loader has a rated operating capacity of 800 kg and a maximum discharge height of 2.3 meters.

What is the bucket capacity of the Yuchai YCH08 skid steer loader?

The Yuchai YCH08 skid steer loader has a bucket capacity of 0.43 cubic meters.

What operator safety features does the Yuchai YCH08 skid steer loader have?

The Yuchai YCH08 skid steer loader is equipped with a cabin that includes ROPS (Roll-Over Protective Structure) for driver protection.

How much is a Yuchai YCH08 Skid steer loader (2017u20132025) worth?

The residual value of the Yuchai YCH08 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
