MCT135D Volvo MCT135D Specifications & Technical Data (2018—2023)
Visit Volvo live at
.jpg){kind=logo}
Technical specs - MCT135D Volvo
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 5.09 t
- Rated operating capacity
- 1360 kg
- Track width
- 400 mm
- Bucket width
- 2.13 m
- Bucket capacity
- 0.5 m³
- Driver protection
- FD
- Transport length
- 3.8 m
- Transport width
- 1.93 m
- Transport height
- 2.08 m
- Travel speed
- 12.6 km/h
- Max. discharge height
- 2.28 m
- Lifting force
- 25.83 kN
- Model series
- MCT
- Engine manuf.
- Kohler
- Engine type
- KDI2504
- Engine power
- 48 kW
- Max. torque
- 305/1500 Nm
- No. of cylinders
- 4
More technical details, like: standard tyres, steering mode, dimension lxwxh, displacement, revolutions at max torque, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. shovel with teeth
Special equipment
- Diesel particulate filter
-
No
- LPG motor
-
No
- Burglar proof system
-
No
Download datasheets (PDF)
Volvo MCT135D FAQ
How much does the Volvo MCT135D skid steer loader weigh?
What are the transport dimensions of the Volvo MCT135D skid steer loader?
What is the travel speed of the Volvo MCT135D skid steer loader?
What is the track width of the Volvo MCT135D skid steer loader?
What power ratings are available for the Volvo MCT135D skid steer loader?
What is the material handling capacity of the Volvo MCT135D skid steer loader?
What are the specifications of the primary work tool bucket on the Volvo MCT135D?
What operator safety and support features does the Volvo MCT135D have?
How much is a Volvo MCT135D Skid steer loader (2018u20132023) worth?
