MC95C Volvo MC95C Specifications & Technical Data (2016—2019)
.jpg)
.jpg)
.jpg)
.jpg)
Visit Volvo live at
.jpg){kind=logo}
Technical specs - MC95C Volvo
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.13 t
- Rated operating capacity
- 862 kg
- Standard tyres
- 10x16.5-8PR
- Bucket width
- 1.68 m
- Bucket capacity
- 0.39 m³
- Driver protection
- KbR
- Steering mode
- AL
- Transport length
- 3.53 m
- Transport width
- 1.6 m
- Transport height
- 1.98 m
- Travel speed
- 12 km/h
- Max. discharge height
- 2.26 m
- Lifting force
- 15.1 kN
- Model series
- MC
- Engine manuf.
- Kohler
- Engine type
- KDI2054TCR
- Engine power
- 45.1 kW
- Displacement
- 2.481 l
- Revolutions at max torque
- 2600 rpm
- Max. torque
- 300/1500 Nm
- No. of cylinders
- 4
- Emission level
- Tier 4 f
More technical details, like: track width, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and std. shovel with teeth
Special equipment
- Diesel particulate filter
-
No
- LPG motor
-
No
- Burglar proof system
-
No
