Technical specs - MC60C Volvo
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 2.75 t
- Rated operating capacity
- 612 kg
- Standard tyres
- 10x16.5-8PR
- Bucket width
- 1.52 m
- Bucket capacity
- 0.36 m³
- Driver protection
- KbR
- Steering mode
- AL
- Transport length
- 3.49 m
- Transport width
- 1.52 m
- Transport height
- 1.98 m
- Travel speed
- 12 km/h
- Max. discharge height
- 2.26 m
- Lifting force
- 13.8 kN
- Model series
- MC
- Engine manuf.
- Kohler
- Engine type
- KDI1903TCR
- Engine power
- 36 kW
- Dimension lxwxh
- 598.3x530x726 mm
- Displacement
- 1.861 l
- Revolutions at max torque
- 2600 rpm
- Max. torque
- 225/1500 Nm
- No. of cylinders
- 3
- Cylinder bore x stroke
- 88x102 mm
- Emission level
- Tier 4 f
Basic model with ROPS cabin and std. shovel with teeth
Special equipment
- Diesel particulate filter
-
No
- LPG motor
-
No
- Burglar proof system
-
No
