MC110 Volvo MC110 Specifications & Technical Data (2003—2005)

The Volvo MC110 is a skid steer loader manufactured by Volvo from 2003 to 2005. It has a weight of 3.472 tons and a transport leng…

The Volvo MC110 is a skid steer loader manufactured by Volvo from 2003 to 2005. It has a weight of 3.472 tons and a transport length of 3.55 meters. The bucket capacity is 0.378 cubic meters, with a bucket width of 1.829 meters. The maximum discharge height is 3.978 meters, and it has a travel speed of 9.6 km/h. The transport width is 1.826 meters, and the transport height is 2.058 meters. The lifting force is 16.63 kilonewtons, and the rated operating capacity is 1043 kilograms.

Skid Steer Loaders Volvo MC110

Visit Volvo live at

Technical specs - MC110 Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.472 t
Rated operating capacity
1043 kg
Standard tyres
12x16.5-10PR
Bucket width
1.829 m
Bucket capacity
0.378 m³
Driver protection
KbR
Steering mode
AL
Transport length
3.55 m
Transport width
1.826 m
Transport height
2.058 m
Travel speed
9.6 km/h
Max. discharge height
3.978 m
Lifting force
16.63 kN
Engine manuf.
Perkins
Engine type
1004.42
Engine power
64 kW
Displacement
4.2 l
Revolutions at max torque
2400 rpm
Max. torque
300/1400 Nm
No. of cylinders
4
Cylinder bore x stroke
103x127 mm

More technical details, like: track width, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Volvo MC110 FAQ

When was the Volvo MC110 manufactured?

The Volvo MC110 was manufactured from 2003 to 2005.

How much does the Volvo MC110 skid steer loader weigh?

The Volvo MC110 skid steer loader weighs 3.47 tons.

What are the transport dimensions of the Volvo MC110 skid steer loader?

The Volvo MC110 has a transport length of 3.55 meters, a transport width of 1.83 meters, and a transport height of 2.06 meters.

What is the travel speed of the Volvo MC110 skid steer loader?

The Volvo MC110 skid steer loader has a travel speed of 9.6 km/h.

What are the standard tyres of the Volvo MC110 skid steer loader?

The Volvo MC110 skid steer loader is equipped with standard tyres sized 12x16.5-10PR.

What is the steering mode of the Volvo MC110?

The Volvo MC110 has all-wheel steering.

What is the lifting force of the Volvo MC110 skid steer loader?

The Volvo MC110 skid steer loader has a lifting force of 16.63 kN.

What is the material handling capacity of the Volvo MC110 skid steer loader?

The Volvo MC110 skid steer loader has a rated operating capacity of 1043 kg and a maximum discharge height of 3.98 meters.

What are the specifications of the primary work tool on the Volvo MC110 skid steer loader?

The primary work tool of the Volvo MC110 skid steer loader has a bucket capacity of 0.38 cubic meters and a bucket width of 1.83 meters.

What operator safety and support features does the Volvo MC110 skid steer loader have?

The Volvo MC110 skid steer loader is equipped with a cabin that includes ROPS (Roll-Over Protective Structure) for driver protection.

How much is a Volvo MC110 Skid steer loader (2003u20132005) worth?

The residual value of the Volvo MC110 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
