MC 70 C Volvo MC 70 C Specifications & Technical Data (2013—2015)

The Volvo MC 70 C is a skid steer loader manufactured from 2013 to 2015. It has a weight of 2.84 tons and a transport length of 3.…

The Volvo MC 70 C is a skid steer loader manufactured from 2013 to 2015. It has a weight of 2.84 tons and a transport length of 3.49 meters. The bucket capacity is 0.39 cubic meters with a width of 1.68 meters. The maximum discharge height is 2.26 meters. It has a travel speed of 12 km/h and a transport width of 1.6 meters. The transport height is 1.98 meters. The lifting force is 17 kN and the rated operating capacity is 703 kg.

Skid Steer Loaders Volvo MC 70 C

Visit Volvo live at

Technical specs - MC 70 C Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.84 t
Rated operating capacity
703 kg
Standard tyres
10x16.5-8PR
Bucket width
1.68 m
Bucket capacity
0.39 m³
Driver protection
KbR
Steering mode
AL
Transport length
3.49 m
Transport width
1.6 m
Transport height
1.98 m
Travel speed
12 km/h
Max. discharge height
2.26 m
Lifting force
17 kN
Model series
MC
Engine manuf.
Perkins
Engine type
404D-22
Engine power
44.7 kW
Displacement
2.2 l
Revolutions at max torque
1800 rpm

More technical details, like: track width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available...

More technical details, like: track width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available, platform, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, engine output - gross, torque, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, heaped capacity, tipping load, operating capacity, speed - maximum, breakout - lift, breakout - bucket, pump type, hydraulic power, hydraulic power - option, pump flow, system pressure, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Volvo MC 70 C FAQ

When was the Volvo MC 70 C manufactured?

The Volvo MC 70 C was manufactured from 2013 to 2015.

How much does the Volvo MC 70 C skid steer loader weigh?

The Volvo MC 70 C skid steer loader weighs 2.84 tons.

What are the transport dimensions of the Volvo MC 70 C skid steer loader?

The Volvo MC 70 C has a transport length of 3.49 meters, a transport width of 1.6 meters, and a transport height of 1.98 meters.

What is the travel speed of the Volvo MC 70 C skid steer loader?

The Volvo MC 70 C skid steer loader has a travel speed of 12 km/h.

What are the undercarriage specifications of the Volvo MC 70 C skid steer loader?

The Volvo MC 70 C skid steer loader is equipped with standard tyres sized 10x16.5-8PR.

What is the steering mode of the Volvo MC 70 C skid steer loader?

The Volvo MC 70 C skid steer loader features all-wheel steering.

What are the power ratings of the Volvo MC 70 C skid steer loader?

The available data does not provide power ratings for the Volvo MC 70 C skid steer loader.

What is the material handling capacity of the Volvo MC 70 C skid steer loader?

The Volvo MC 70 C skid steer loader has a rated operating capacity of 703 kg and a maximum discharge height of 2.26 meters.

What are the specifications of the primary work tool on the Volvo MC 70 C skid steer loader?

The primary work tool of the Volvo MC 70 C skid steer loader has a bucket capacity of 0.39 cubic meters and a bucket width of 1.68 meters.

What operator safety and support features does the Volvo MC 70 C have?

The Volvo MC 70 C is equipped with a cabin that includes ROPS for driver protection.

How much is a Volvo MC 70 C Skid steer loader (2013u20132015) worth?

The residual value of the Volvo MC 70 C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
