PT 80 Terex PT 80 Specifications & Technical Data (2012—2017)

The Terex PT 80 is a skid steer loader manufactured by Terex from 2012 to 2017. It has a weight of 4.07 tons and a transport lengt…

The Terex PT 80 is a skid steer loader manufactured by Terex from 2012 to 2017. It has a weight of 4.07 tons and a transport length of 3.63 meters. The maximum discharge height is 2.515 meters and it has a travel speed of 14 km/h. The transport width is 1.78 meters and the transport height is 2.21 meters. The track width is 460 mm and it has a rated operating capacity of 1406 kg.

Skid Steer Loaders Terex PT 80
Skid Steer Loaders Terex PT 80
Skid Steer Loaders Terex PT 80
Skid Steer Loaders Terex PT 80
Skid Steer Loaders Terex PT 80
Skid Steer Loaders Terex PT 80

Technical specs - PT 80 Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.07 t
Rated operating capacity
1406 kg
Track width
460 mm
Driver protection
Kb
Transport length
3.63 m
Transport width
1.78 m
Transport height
2.21 m
Travel speed
14 km/h
Max. discharge height
2.515 m
Model series
PT
Engine manuf.
Perkins
Engine type
804D-33T
Engine power
59 kW
Displacement
3.3 l
Revolutions at max torque
1600 rpm

More technical details, like: standard tyres, bucket width, bucket capacity, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, undercarriage type, lift geometry...

More technical details, like: standard tyres, bucket width, bucket capacity, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, undercarriage type, lift geometry, access, suspension seat, telematics available, engine manufacturer, engine model, emission rating, number of cylinders, aspiration, rated speed, engine output - net, engine output - gross, torque, transmission type, drive method, track rollers, track shoe width, length - no bucket, length - with bucket, width - no bucket, height - top of cab, ground clearance, track length on ground, height to hinge pin, dump angle, dump height - maximum, fuel tank, tipping load, operating capacity, ground bearing pressure, speed - maximum, hydraulic power, hydraulic power - option, pump flow, pump flow - option, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Terex PT 80 FAQ

When was the Terex PT 80 manufactured?

The Terex PT 80 was manufactured from 2012 to 2017.

How much does the Terex PT 80 skid steer loader weigh?

The Terex PT 80 skid steer loader weighs 4.07 tons.

What are the transport dimensions of the Terex PT 80 skid steer loader?

The Terex PT 80 has a transport length of 3.63 meters, a transport width of 1.78 meters, and a transport height of 2.21 meters.

What is the travel speed of the Terex PT 80 skid steer loader?

The Terex PT 80 has a travel speed of 14 km/h.

What is the track width of the Terex PT 80 skid steer loader?

The Terex PT 80 skid steer loader has a track width of 460 mm.

What is the material handling capacity of the Terex PT 80 skid steer loader?

The Terex PT 80 skid steer loader has a rated operating capacity of 1406 kg and a maximum discharge height of 2.52 meters.

What operator safety and support features does the Terex PT 80 skid steer loader have?

The Terex PT 80 skid steer loader has driver protection in the form of a cabin.

How much is a Terex PT 80 Skid steer loader (2012u20132017) worth?

The residual value of the Terex PT 80 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
