PT 60 Terex PT 60 Specifications & Technical Data (2012—2017)

The Terex PT 60 is a skid steer loader manufactured by Terex from 2012 to 2017. It has a weight of 2.88 tons and a transport lengt…

The Terex PT 60 is a skid steer loader manufactured by Terex from 2012 to 2017. It has a weight of 2.88 tons and a transport length of 3.25 meters. The maximum discharge height is 2.31 meters, and it has a travel speed of 16 km/h. The transport width is 1.68 meters, and the transport height is 1.96 meters. The track width is 380 millimeters, and the rated operating capacity is 862 kilograms.

Skid Steer Loaders Terex PT 60
Skid Steer Loaders Terex PT 60
Skid Steer Loaders Terex PT 60
Skid Steer Loaders Terex PT 60

Technical specs - PT 60 Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.88 t
Rated operating capacity
862 kg
Track width
380 mm
Driver protection
Kb
Transport length
3.25 m
Transport width
1.68 m
Transport height
1.96 m
Travel speed
16 km/h
Max. discharge height
2.31 m
Model series
PT
Engine manuf.
Perkins
Engine type
404D-22T
Engine power
42 kW
Displacement
2.2 l
Revolutions at max torque
1800 rpm

More technical details, like: standard tyres, bucket width, bucket capacity, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, undercarriage type, lift geometry...

More technical details, like: standard tyres, bucket width, bucket capacity, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, undercarriage type, lift geometry, access, suspension seat, telematics available, engine manufacturer, engine model, emission rating, number of cylinders, aspiration, rated speed, engine output - net, engine output - gross, rated speed - torque, torque, transmission type, drive method, track rollers, track shoe width, length - no bucket, length - with bucket, width - no bucket, height - top of cab, ground clearance, track length on ground, height to hinge pin, dump height - maximum, fuel tank, tipping load, operating capacity, ground bearing pressure, speed - maximum, hydraulic power, pump flow, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Terex PT 60 FAQ

When was the Terex PT 60 manufactured?

The Terex PT 60 was manufactured from 2012 to 2017.

How much does the Terex PT 60 skid steer loader weigh?

The Terex PT 60 skid steer loader weighs 2.88 tons.

What are the transport dimensions of the Terex PT 60 skid steer loader?

The Terex PT 60 has transport dimensions of 3.25 meters in length, 1.68 meters in width, and 1.96 meters in height.

What is the travel speed of the Terex PT 60 skid steer loader?

The Terex PT 60 has a travel speed of 16 km/h.

What is the track width of the Terex PT 60's undercarriage?

The Terex PT 60 has a track width of 380 mm on its undercarriage.

What is the material handling capacity of the Terex PT 60 skid steer loader?

The Terex PT 60 skid steer loader has a rated operating capacity of 862 kilograms.

What operator safety feature does the Terex PT 60 skid steer loader have?

The Terex PT 60 skid steer loader is equipped with a driver protection cabin for operator safety.

How much is a Terex PT 60 Skid steer loader (2012u20132017) worth?

The residual value of the Terex PT 60 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
