TL 8 Takeuchi TL 8 Specifications & Technical Data (2015—2025)

Model rating
6,00 / 10

The Takeuchi TL 8 is a skid steer loader manufactured since 2015. It has a weight of 3.91 tons and a transport length of 3.43 mete…

The Takeuchi TL 8 is a skid steer loader manufactured since 2015. It has a weight of 3.91 tons and a transport length of 3.43 meters. The bucket capacity is 0.35 cubic meters with a width of 1.67 meters. The maximum discharge height is 2.37 meters. It has a travel speed of 11 km/h and a transport width of 1.58 meters. The transport height is 2.23 meters. The lifting force is 30.5 kN and the track width is 320 mm. The rated operating capacity is 955 kg. It is equipped with a diesel particulate filter.

Skid Steer Loaders Takeuchi TL 8
Skid Steer Loaders Takeuchi TL 8
Skid Steer Loaders Takeuchi TL 8
Skid Steer Loaders Takeuchi TL 8
Skid Steer Loaders Takeuchi TL 8
Skid Steer Loaders Takeuchi TL 8

Technical specs - TL 8 Takeuchi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.91 t
Rated operating capacity
955 kg
Track width
320 mm
Bucket width
1.67 m
Bucket capacity
0.35 m³
Driver protection
Kb
Transport length
3.43 m
Transport width
1.58 m
Transport height
2.23 m
Travel speed
11 km/h
Max. discharge height
2.37 m
Lifting force
30.5 kN
Model series
TL
Engine manuf.
Kubota
Engine type
V3307CR
Engine power
54 kW
Displacement
3.33 l
Revolutions at max torque
1500 rpm
Max. torque
261 Nm
Emission level
Tier 4/Stage V

More technical details, like: standard tyres, steering mode, dimension lxwxh, no. of cylinders, cylinder bore x stroke, undercarriage type, lift geometry, access, suspension seat, telematics available, platform, security system available...

More technical details, like: standard tyres, steering mode, dimension lxwxh, no. of cylinders, cylinder bore x stroke, undercarriage type, lift geometry, access, suspension seat, telematics available, platform, security system available, engine manufacturer, engine model, emission rating, number of cylinders, emissions technology, after treatment system, after treatment system 2, aspiration, rated speed, engine output - gross, rated speed - torque, torque, transmission type, drive method, track rollers, track shoe width, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, track length on ground, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, heaped capacity, tipping load, operating capacity, ground bearing pressure, speed - maximum, breakout - lift, breakout - bucket, hydraulic power, hydraulic power - option, pump flow, pump flow - option, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
Yes
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Takeuchi TL 8 FAQ

When was the Takeuchi TL 8 manufactured?

The Takeuchi TL 8 was manufactured from 2015 to 2025.

How much does the Takeuchi TL 8 skid steer loader weigh?

The Takeuchi TL 8 skid steer loader weighs 3.91 tons.

What are the transport dimensions of the Takeuchi TL 8 skid steer loader?

The Takeuchi TL 8 skid steer loader has a transport length of 3.43 meters, a transport width of 1.58 meters, and a transport height of 2.23 meters.

What is the travel speed of the Takeuchi TL 8 skid steer loader?

The Takeuchi TL 8 skid steer loader has a travel speed of 11 km/h.

What is the track width of the Takeuchi TL 8 skid steer loader?

The Takeuchi TL 8 skid steer loader has a track width of 320 mm.

What is the power rating of the Takeuchi TL 8 skid steer loader?

The source data does not provide a power rating for the Takeuchi TL 8 skid steer loader.

What is the material handling capacity of the Takeuchi TL 8 skid steer loader?

The Takeuchi TL 8 skid steer loader has a rated operating capacity of 955 kg and a maximum discharge height of 2.37 meters.

What are the specifications of the primary work tool bucket on the Takeuchi TL 8?

The primary work tool bucket of the Takeuchi TL 8 has a capacity of 0.35 cubic meters and a width of 1.67 meters.

What operator safety features does the Takeuchi TL 8 have?

The Takeuchi TL 8 has a cabin for driver protection.

How much is a Takeuchi TL 8 Skid steer loader (2015u20132025) worth?

The residual value of the Takeuchi TL 8 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
