N 40 Neumeier N 40 Specifications & Technical Data (2006—2012)

The Neumeier N 40 is a skid steer loader manufactured from 2006 to 2012. It has a weight of 2.7 tons and a transport length of 3.2…

The Neumeier N 40 is a skid steer loader manufactured from 2006 to 2012. It has a weight of 2.7 tons and a transport length of 3.264 meters. The bucket capacity is 0.27 cubic meters with a width of 1.62 meters. The maximum discharge height is 2.1 meters and the transport width is 1.7 meters. It has a rated operating capacity of 900 kilograms.

Skid Steer Loaders Neumeier N 40

Technical specs - N 40 Neumeier

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.7 t
Rated operating capacity
900 kg
Standard tyres
10x16.5
Bucket width
1.62 m
Bucket capacity
0.27 m³
Driver protection
KbR
Steering mode
PL
Transport length
3.264 m
Transport width
1.7 m
Travel speed
10.5 km/h
Max. discharge height
2.1 m
Model series
N
Engine manuf.
Yangdong
Engine type
Y 485 EPA
Engine power
29.8 kW
Revolutions at max torque
2650 rpm

More technical details, like: track width, transport height, lifting force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine model...

More technical details, like: track width, transport height, lifting force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine model, rated speed, engine output - net, transmission type, tyre size, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, height to hinge pin, reach - max dump height, fuel tank, heaped capacity, tipping load, operating capacity, speed - maximum, pump flow, system pressure, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Neumeier N 40 FAQ

When was the Neumeier N 40 manufactured?

The Neumeier N 40 was manufactured from 2006 to 2012.

How much does the Neumeier N 40 skid steer loader weigh?

The Neumeier N 40 skid steer loader weighs 2.7 tons.

What are the transport dimensions of the Neumeier N 40 skid steer loader?

The Neumeier N 40 has a transport length of 3.26 meters and a transport width of 1.7 meters.

What is the travel speed of the Neumeier N 40 skid steer loader?

The Neumeier N 40 skid steer loader has a travel speed of 10.5 km/h.

What is the standard tyre size of the Neumeier N 40 skid steer loader?

The Neumeier N 40 skid steer loader has standard tyres sized 10x16.5.

What is the steering mode of the Neumeier N 40 skid steer loader?

The Neumeier N 40 skid steer loader has a tank steering mode.

What is the material handling capacity of the Neumeier N 40 skid steer loader?

The Neumeier N 40 skid steer loader has a rated operating capacity of 900 kg and a maximum discharge height of 2.1 meters.

What are the specifications of the primary work tool bucket on the Neumeier N 40 skid steer loader?

The Neumeier N 40 skid steer loader has a bucket with a capacity of 0.27 cubic meters and a width of 1.62 meters.

What operator safety features does the Neumeier N 40 skid steer loader have?

The Neumeier N 40 skid steer loader features a cabin with ROPS for driver protection.
