2700V Mustang 2700V Specifications & Technical Data (2011—2018)

Model rating
9,00 / 10

The Mustang 2700V Skid Steer Loader, manufactured from 2011 to 2018, weighs 3.63 tons and has a transport length of 3.79 meters. I…

The Mustang 2700V Skid Steer Loader, manufactured from 2011 to 2018, weighs 3.63 tons and has a transport length of 3.79 meters. It features a bucket width of 1.83 meters and a maximum discharge height of 2.51 meters. With a travel speed of 13 km/h, it has a transport width of 1.66 meters and a transport height of 2.04 meters. This construction machine has a rated operating capacity of 1225 kilograms.

Skid Steer Loaders Mustang 2700V
Skid Steer Loaders Mustang 2700V
Skid Steer Loaders Mustang 2700V
Skid Steer Loaders Mustang 2700V

Technical specs - 2700V Mustang

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.63 t
Rated operating capacity
1225 kg
Standard tyres
12.00x16.5
Bucket width
1.83 m
Driver protection
Kb
Steering mode
AL
Transport length
3.79 m
Transport width
1.66 m
Transport height
2.04 m
Travel speed
13 km/h
Max. discharge height
2.51 m
Model series
Radialhub
Engine manuf.
Yanmar
Engine type
4TNV98T
Engine power
62.6 kW
Displacement
3.3 l
Revolutions at max torque
2500 rpm

More technical details, like: track width, bucket capacity, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, rating standard - rops, rating standard - fops...

More technical details, like: track width, bucket capacity, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, torque, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, tipping load, operating capacity, speed - maximum, pump type, hydraulic power, hydraulic power - option, pump flow, system pressure, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Mustang 2700V FAQ

When was the Mustang 2700V manufactured?

The Mustang 2700V was manufactured from 2011 to 2018.

How much does the Mustang 2700V skid steer loader weigh?

The Mustang 2700V skid steer loader weighs 3.63 tons.

What are the transport dimensions of the Mustang 2700V skid steer loader?

The Mustang 2700V has a transport length of 3.79 meters, a transport width of 1.66 meters, and a transport height of 2.04 meters.

What is the travel speed of the Mustang 2700V skid steer loader?

The Mustang 2700V has a travel speed of 13 km/h.

What are the undercarriage specifications of the Mustang 2700V skid steer loader?

The Mustang 2700V skid steer loader is equipped with standard tyres sized 12.00x16.5.

What is the steering mode of the Mustang 2700V skid steer loader?

The Mustang 2700V skid steer loader has an all-wheel steering mode.

What is the material handling capacity of the Mustang 2700V skid steer loader?

The Mustang 2700V skid steer loader has a rated operating capacity of 1225 kg and a maximum discharge height of 2.51 meters.

What is the bucket width of the Mustang 2700V skid steer loader?

The Mustang 2700V skid steer loader has a bucket width of 1.83 meters.

What operator safety features does the Mustang 2700V have?

The Mustang 2700V has a cabin for driver protection.
