2076 Mustang 2076 Specifications & Technical Data (2011—2016)

Model rating
6,00 / 10

The Mustang 2076 is a skid steer loader manufactured by Mustang from 2011 to 2016. It has a weight of 3.39 tons and a transport le…

The Mustang 2076 is a skid steer loader manufactured by Mustang from 2011 to 2016. It has a weight of 3.39 tons and a transport length of 3.28 meters. The bucket capacity is 0.43 cubic meters, with a bucket width of 1.76 meters. The maximum discharge height is 2.41 meters, and it has a travel speed of 18 km/h. The transport width is 1.71 meters, and the transport height is 2.06 meters. The rated operating capacity is 998 kilograms.

Skid Steer Loaders Mustang 2076
Skid Steer Loaders Mustang 2076
Skid Steer Loaders Mustang 2076
Skid Steer Loaders Mustang 2076
Skid Steer Loaders Mustang 2076
Skid Steer Loaders Mustang 2076

Technical specs - 2076 Mustang

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.39 t
Rated operating capacity
998 kg
Standard tyres
12.00x16.5
Bucket width
1.76 m
Bucket capacity
0.43 m³
Driver protection
Kb
Steering mode
AL
Transport length
3.28 m
Transport width
1.71 m
Transport height
2.06 m
Travel speed
18 km/h
Max. discharge height
2.41 m
Engine manuf.
Yanmar
Engine type
4TNV98T
Engine power
62.9 kW
Displacement
3.3 l
Revolutions at max torque
1850 rpm

More technical details, like: track width, lifting force, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, rating standard - rops, rating standard - fops...

More technical details, like: track width, lifting force, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, lift height, turning radius - rear corner, turning radius - bucket corner, fuel tank, tipping load, operating capacity, speed - maximum, breakout - lift, breakout - bucket, pump type, hydraulic power, hydraulic power - option, pump flow, system pressure, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Mustang 2076 FAQ

When was the Mustang 2076 skid steer loader manufactured?

The Mustang 2076 skid steer loader was manufactured from 2011 to 2016.

How much does the Mustang 2076 skid steer loader weigh?

The Mustang 2076 skid steer loader weighs 3.39 tons.

What are the transport dimensions of the Mustang 2076 skid steer loader?

The Mustang 2076 skid steer loader has a transport length of 3.28 meters, a transport width of 1.71 meters, and a transport height of 2.06 meters.

What is the travel speed of the Mustang 2076 skid steer loader?

The Mustang 2076 skid steer loader has a travel speed of 18 km/h.

What is the standard tyre size of the Mustang 2076 skid steer loader?

The Mustang 2076 skid steer loader has standard tyres sized 12.00x16.5.

What is the steering mode of the Mustang 2076 skid steer loader?

The Mustang 2076 skid steer loader has all-wheel steering.

What is the material handling capacity of the Mustang 2076 skid steer loader?

The Mustang 2076 skid steer loader has a rated operating capacity of 998 kg and a maximum discharge height of 2.41 meters.

What are the specifications of the primary work tool on the Mustang 2076 skid steer loader?

The primary work tool of the Mustang 2076 skid steer loader has a bucket capacity of 0.43 cubic meters and a bucket width of 1.76 meters.

What operator safety features does the Mustang 2076 have?

The Mustang 2076 has driver protection in the form of a cabin.

How much is a Mustang 2076 Skid steer loader (2011u20132016) worth?

The residual value of the Mustang 2076 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Reviews

Model rating
6,00 / 10
Quotation mark

Mustang Gregg, Mustang 2076 user from

Great skid steer. It is very reliable and rugged. I like it for almost everything over my Cat 242B. The specs stated claim it has a Yanmar engine, but mine has a Cummins.

Mustang 2076 overview

Engine

Advanced

A 70.7-hp Yanmar Interim Tier IV-certified turbocharged diesel engine keeps this machine powered up and ready to work.


Drive system

Fast

Travel speeds up to 12.3 mph when equipped with the two-speed drive option. Hydraglide ride control is standard.
