2056 Mustang 2056 Specifications & Technical Data (2011—2016)

Model rating
6,00 / 10

The Mustang 2056 is a skid steer loader manufactured by Mustang from 2011 to 2016. It has a weight of 3.08 tons and a transport le…

The Mustang 2056 is a skid steer loader manufactured by Mustang from 2011 to 2016. It has a weight of 3.08 tons and a transport length of 3.21 meters. The bucket capacity is 0.37 cubic meters, with a bucket width of 1.68 meters. The maximum discharge height is 2.29 meters, and it has a travel speed of 19 km/h. The transport width is 1.58 meters, and the transport height is 1.98 meters. The rated operating capacity is 862 kilograms.

Skid Steer Loaders Mustang 2056
Skid Steer Loaders Mustang 2056
Skid Steer Loaders Mustang 2056
Skid Steer Loaders Mustang 2056
Skid Steer Loaders Mustang 2056
Skid Steer Loaders Mustang 2056

Technical specs - 2056 Mustang

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.08 t
Rated operating capacity
862 kg
Standard tyres
10x16.5
Bucket width
1.68 m
Bucket capacity
0.37 m³
Driver protection
Kb
Steering mode
AL
Transport length
3.21 m
Transport width
1.58 m
Transport height
1.98 m
Travel speed
19 km/h
Max. discharge height
2.29 m
Model series
II
Engine manuf.
Deutz
Engine type
TD2009
Engine power
64 kW
Displacement
2.3 l
Revolutions at max torque
2500 rpm

More technical details, like: track width, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, rating standard - rops, rating standard - fops, telematics available...

More technical details, like: track width, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, lift height, turning radius - rear corner, turning radius - bucket corner, fuel tank, tipping load, operating capacity, speed - maximum, pump type, hydraulic power, hydraulic power - option, pump flow, system pressure, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Mustang 2056 FAQ

When was the Mustang 2056 skid steer loader manufactured?

The Mustang 2056 skid steer loader was manufactured from 2011 to 2016.

How much does the Mustang 2056 skid steer loader weigh?

The Mustang 2056 skid steer loader weighs 3.08 tons.

What are the transport dimensions of the Mustang 2056 skid steer loader?

The Mustang 2056 skid steer loader has a transport length of 3.21 meters, a transport width of 1.58 meters, and a transport height of 1.98 meters.

What is the travel speed of the Mustang 2056 skid steer loader?

The Mustang 2056 skid steer loader has a travel speed of 19 km/h.

What is the standard tyre size of the Mustang 2056 skid steer loader?

The Mustang 2056 skid steer loader has standard tyres sized 10x16.5.

What is the steering mode of the Mustang 2056 skid steer loader?

The Mustang 2056 skid steer loader has all-wheel steering.

What is the material handling capacity of the Mustang 2056 skid steer loader?

The Mustang 2056 skid steer loader has a rated operating capacity of 862 kg and a maximum discharge height of 2.29 meters.

What are the specifications of the primary work tool bucket on the Mustang 2056 skid steer loader?

The Mustang 2056 skid steer loader has a bucket with a capacity of 0.37 cubic meters and a width of 1.68 meters.

What operator safety and support features does the Mustang 2056 have?

The Mustang 2056 provides operator safety with a driver protection cabin.

How much is a Mustang 2056 Skid steer loader (2011u20132016) worth?

The residual value of the Mustang 2056 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
