570 John Deere Construction 570 Specifications & Technical Data (1987—2021)
Technical specs - 570 John Deere Construction
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.515 t
- Standard tyres
- 27x8.50-15
- Bucket capacity
- 0.31 m³
- Driver protection
- KbR
- Transport length
- 2.959 m
- Transport width
- 1.283 m
- Transport height
- 1.822 m
- Travel speed
- 12.1 km/h
- Max. discharge height
- 2.508 m
- Model series
- 500
- Engine manuf.
- Continental
- Engine type
- TM13
- Engine power
- 23.12 kW
- Displacement
- 1.342 l
- No. of cylinders
- 2
More technical details, like: rated operating capacity, track width, bucket width, steering mode, lifting force, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. shovel with teeth
Special equipment
- Diesel particulate filter
-
No
- LPG motor
-
No
- Burglar proof system
-
No
Download datasheets (PDF)
