300T JCB 300T Specifications & Technical Data (2012—2026)

The JCB 300T is a skid steer loader manufactured by JCB since 2012. It has a weight of 5.08 tons and a transport length of 3.78 me…

The JCB 300T is a skid steer loader manufactured by JCB since 2012. It has a weight of 5.08 tons and a transport length of 3.78 meters. The bucket capacity is 0.64 cubic meters, with a bucket width of 2.13 meters. The maximum discharge height is 3.18 meters, and it has a travel speed of 12.6 km/h. The transport width is 2.13 meters, and the transport height is 2.08 meters. The track width is 450 millimeters, and the rated operating capacity is 1361 kilograms.

Skid Steer Loaders JCB 300T

Visit JCB live at

Technical specs - 300T JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.08 t
Rated operating capacity
1361 kg
Track width
450 mm
Bucket width
2.13 m
Bucket capacity
0.64 m³
Driver protection
KbR
Transport length
3.78 m
Transport width
2.13 m
Transport height
2.08 m
Travel speed
12.6 km/h
Max. discharge height
3.18 m
Engine manuf.
JCB
Engine type
DieselMax TC-68
Engine power
68.6 kW
Displacement
4.3 l
Revolutions at max torque
2400 rpm
Max. torque
408 Nm
No. of cylinders
4
Emission level
EPA-T3

More technical details, like: standard tyres, steering mode, lifting force, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

JCB 300T FAQ

When was the JCB 300T skid steer loader manufactured?

The JCB 300T skid steer loader was first produced in 2012.

How much does the JCB 300T skid steer loader weigh?

The JCB 300T skid steer loader weighs 5.08 tons.

What are the transport dimensions of the JCB 300T skid steer loader?

The JCB 300T skid steer loader has a transport length of 3.78 meters, a transport width of 2.13 meters, and a transport height of 2.08 meters.

What is the travel speed of the JCB 300T skid steer loader?

The JCB 300T has a travel speed of 12.6 km/h.

What is the track width of the undercarriage on the JCB 300T skid steer loader?

The JCB 300T skid steer loader has a track width of 450 mm on its undercarriage.

What is the material handling capacity of the JCB 300T skid steer loader?

The JCB 300T skid steer loader has a rated operating capacity of 1361 kg and a maximum discharge height of 3.18 meters.

What are the specifications of the primary work tool on the JCB 300T skid steer loader?

The JCB 300T skid steer loader has a bucket with a capacity of 0.64 cubic meters and a width of 2.13 meters.

What operator safety and support features does the JCB 300T have?

The JCB 300T is equipped with a cabin that includes ROPS (Roll-Over Protective Structure) for driver protection.

How much is a JCB 300T Skid steer loader (2012u20132025) worth?

The residual value of the JCB 300T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
