Technical specs - 300 JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 4.21 t
- Rated operating capacity
- 1445 kg
- Standard tyres
- 12x16.5-10 PR
- Bucket width
- 2.13 m
- Bucket capacity
- 0.51 m³
- Driver protection
- KbR
- Steering mode
- AL
- Transport length
- 3.8 m
- Transport width
- 1.8 m
- Transport height
- 2.1 m
- Travel speed
- 10.9 km/h
- Max. discharge height
- 2.3 m
- Lifting force
- 29.1 kN
- Engine manuf.
- JCB
- Engine type
- EcoMax TCAE
- Engine power
- 55 kW
- Displacement
- 4.4 l
- Revolutions at max torque
- 1300 rpm
- Max. torque
- 400 Nm
- Cylinder bore x stroke
- 103x132 mm
More technical details, like: track width, model series, dimension lxwxh, no. of cylinders, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. shovel with teeth
Special equipment
- Diesel particulate filter
-
No
- LPG motor
-
No
- Burglar proof system
-
No
Download datasheets (PDF)
