270 JCB 270 Specifications & Technical Data (2017—2021)

The JCB 270 is a skid steer loader manufactured by JCB from 2017 to 2021. It has a weight of 3.94 tons and a transport length of 3…

The JCB 270 is a skid steer loader manufactured by JCB from 2017 to 2021. It has a weight of 3.94 tons and a transport length of 3.8 meters. The bucket capacity is 0.47 cubic meters, with a bucket width of 1.98 meters. The maximum discharge height is 2.3 meters. The transport width is 1.8 meters, and the transport height is 2.1 meters. The lifting force is 29.1 kilonewtons, and the rated operating capacity is 1235 kilograms.

Skid Steer Loaders JCB 270

Visit JCB live at

Technical specs - 270 JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.94 t
Rated operating capacity
1235 kg
Standard tyres
12x16.5-10 PR
Bucket width
1.98 m
Bucket capacity
0.47 m³
Driver protection
KbR
Steering mode
AL
Transport length
3.8 m
Transport width
1.8 m
Transport height
2.1 m
Travel speed
10.9 km/h
Max. discharge height
2.3 m
Lifting force
29.1 kN
Engine manuf.
JCB
Engine type
EcoMax TCAE
Engine power
55 kW
Displacement
4.4 l
Revolutions at max torque
1300 rpm
Max. torque
400 Nm
Cylinder bore x stroke
103x132 mm

More technical details, like: track width, model series, dimension lxwxh, no. of cylinders, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

JCB 270 FAQ

When was the JCB 270 skid steer loader manufactured?

The JCB 270 skid steer loader was manufactured from 2017 to 2021.

How much does the JCB 270 skid steer loader weigh?

The JCB 270 skid steer loader weighs 3.94 tons.

What are the transport dimensions of the JCB 270 skid steer loader?

The JCB 270 skid steer loader has a transport length of 3.8 meters, a transport width of 1.8 meters, and a transport height of 2.1 meters.

What is the travel speed of the JCB 270 skid steer loader?

The JCB 270 skid steer loader has a travel speed of 10.9 km/h.

What is the undercarriage specification of the JCB 270 skid steer loader?

The JCB 270 skid steer loader is equipped with standard tyres of size 12x16.5-10 PR.

What is the steering mode of the JCB 270 skid steer loader?

The JCB 270 skid steer loader has an all-wheel steering mode.

What is the lifting force rating of the JCB 270 skid steer loader?

The JCB 270 skid steer loader has a lifting force of 29.1 kN.

What is the material handling capacity of the JCB 270 skid steer loader?

The JCB 270 skid steer loader has a rated operating capacity of 1235 kg and a maximum discharge height of 2.3 meters.

What are the specifications of the primary work tool bucket on the JCB 270 skid steer loader?

The JCB 270 skid steer loader has a bucket with a capacity of 0.47 cubic meters and a width of 1.98 meters.

What operator safety and support features does the JCB 270 skid steer loader have?

The JCB 270 skid steer loader features a cabin with ROPS for driver protection.

How much is a JCB 270 Skid steer loader (2017u20132021) worth?

The residual value of the JCB 270 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
