R260 Gehl R260 Specifications & Technical Data (2015—2026)

The Gehl R260 is a skid steer loader manufactured by Gehl since 2015. It has a weight of 3.72 tons and a transport length of 3.63 …

The Gehl R260 is a skid steer loader manufactured by Gehl since 2015. It has a weight of 3.72 tons and a transport length of 3.63 meters. The bucket capacity is 0.6 cubic meters, with a bucket width of 1.83 meters. The maximum discharge height is 2.39 meters, and it has a travel speed of 12.9 km/h. The transport width is 1.66 meters, and the transport height is 2.06 meters. The rated operating capacity is 1179 kilograms.

R260

Years of manufacture: 2015—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - R260 Gehl

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.72 t

Rated operating capacity: 1179 kg

Standard tyres: 12.00x16.5

Bucket width: 1.83 m

Bucket capacity: 0.6 m³

Driver protection: KbR

Steering mode: PL

Transport length: 3.63 m

Transport width: 1.66 m

Transport height: 2.06 m

Travel speed: 12.9 km/h

Max. discharge height: 2.39 m

Model series: R

Engine manuf.: Yanmar

Engine type: 4TNV98C-NMS

Engine power: 53.7 kW

Displacement: 3.3 l

Revolutions at max torque: 2500 rpm

Max. torque: 294/1625 Nm

No. of cylinders: 4

Emission level: Tier IV

More technical details, like: track width, lifting force, dimension lxwxh, cylinder bore x stroke, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available, engine manufacturer, engine model, emission rating, after treatment system, aspiration, rated speed, engine output - net, engine output - gross, torque, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, tipping load, operating capacity, speed - maximum, pump flow, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter: No
LPG motor: No
Burglar proof system: No

Download datasheets (PDF)

Gehl R260 FAQ

When was the Gehl R260 manufactured?

The Gehl R260 was first produced in 2015.

How much does the Gehl R260 skid steer loader weigh?

The Gehl R260 skid steer loader weighs 3.72 tons.

What are the transport dimensions of the Gehl R260 skid steer loader?

The Gehl R260 skid steer loader has a transport length of 3.63 meters, a transport width of 1.66 meters, and a transport height of 2.06 meters.

What is the travel speed of the Gehl R260 skid steer loader?

The Gehl R260 skid steer loader has a travel speed of 12.9 km/h.

What are the undercarriage specifications of the Gehl R260 skid steer loader?

The Gehl R260 skid steer loader is equipped with standard tyres sized 12.00x16.5.

What is the steering mode of the Gehl R260 skid steer loader?

The Gehl R260 skid steer loader has tank steering.

What is the material handling capacity of the Gehl R260 skid steer loader?

The Gehl R260 skid steer loader has a rated operating capacity of 1179 kg and a maximum discharge height of 2.39 meters.

What are the specifications of the primary work tool on the Gehl R260 skid steer loader?

The Gehl R260 skid steer loader has a bucket with a capacity of 0.6 cubic meters and a width of 1.83 meters.

What operator safety and support features does the Gehl R260 have?

The Gehl R260 is equipped with a cabin with ROPS for driver protection.

How much is a Gehl R260 Skid steer loader (2015u20132025) worth?

The residual value of the Gehl R260 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
