R190 Gehl R190 Specifications & Technical Data (2015—2026)

The Gehl R190 is a skid steer loader manufactured by Gehl since 2015. It has a weight of 3.12 tons and a transport length of 3.23 …

The Gehl R190 is a skid steer loader manufactured by Gehl since 2015. It has a weight of 3.12 tons and a transport length of 3.23 meters. The bucket capacity is 0.48 cubic meters, with a bucket width of 1.68 meters. The maximum discharge height is 2.31 meters, and it has a travel speed of 12.1 km/h. The transport width is 1.64 meters, and the transport height is 2.03 meters. The rated operating capacity is 862 kilograms.

Skid Steer Loaders Gehl R190
Skid Steer Loaders Gehl R190
Skid Steer Loaders Gehl R190
Skid Steer Loaders Gehl R190
Skid Steer Loaders Gehl R190
Skid Steer Loaders Gehl R190
Skid Steer Loaders Gehl R190
Skid Steer Loaders Gehl R190

Technical specs - R190 Gehl

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.12 t
Rated operating capacity
862 kg
Standard tyres
10.00x16.5
Bucket width
1.68 m
Bucket capacity
0.48 m³
Driver protection
KbR
Steering mode
PL
Transport length
3.23 m
Transport width
1.64 m
Transport height
2.03 m
Travel speed
12.1 km/h
Max. discharge height
2.31 m
Model series
R
Engine manuf.
Yanmar
Engine type
4TNV98C-NMS
Engine power
51.7 kW
Displacement
3.3 l
Revolutions at max torque
2500 rpm
Max. torque
241.3/1625 Nm
No. of cylinders
4
Emission level
Tier IV

More technical details, like: track width, lifting force, dimension lxwxh, cylinder bore x stroke, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available, engine manufacturer, engine model...

More technical details, like: track width, lifting force, dimension lxwxh, cylinder bore x stroke, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available, engine manufacturer, engine model, emission rating, after treatment system, aspiration, rated speed, engine output - net, engine output - gross, torque, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, tipping load, operating capacity, speed - maximum, pump flow, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Gehl R190 FAQ

When was the Gehl R190 manufactured?

The Gehl R190 was first produced in 2015.

How much does the Gehl R190 skid steer loader weigh?

The Gehl R190 skid steer loader weighs 3.12 tons.

What are the transport dimensions of the Gehl R190 skid steer loader?

The Gehl R190 skid steer loader has a transport length of 3.23 meters, a transport width of 1.64 meters, and a transport height of 2.03 meters.

What is the travel speed of the Gehl R190 skid steer loader?

The Gehl R190 skid steer loader has a travel speed of 12.1 km/h.

What are the undercarriage specifications of the Gehl R190 skid steer loader?

The Gehl R190 skid steer loader is equipped with standard tyres sized 10.00x16.5.

What is the steering mode of the Gehl R190?

The Gehl R190 has a steering mode of tank steering.

What is the material handling capacity of the Gehl R190 skid steer loader?

The Gehl R190 has a rated operating capacity of 862 kg and a maximum discharge height of 2.31 meters.

What are the specifications of the primary work tool bucket on the Gehl R190 skid steer loader?

The primary work tool bucket of the Gehl R190 has a capacity of 0.48 cubic meters and a width of 1.68 meters.

What operator safety and support features does the Gehl R190 skid steer loader have?

The Gehl R190 skid steer loader features a cabin with ROPS for driver protection.

How much is a Gehl R190 Skid steer loader (2015u20132025) worth?

The residual value of the Gehl R190 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
