R164 Gehl R164 Specifications & Technical Data (2026—2026)

Rated operating capacity: 748kg – Standard tyres: 10 x 16.5 - 10 PR HD – Bucket width: 1.562m – Driver protection: KbR – Transport length: 2.39m – Transport width: 1.582m

Technical specs - R164 Gehl

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Rated operating capacity
748 kg
Standard tyres
10 x 16.5 - 10 PR HD
Bucket width
1.562 m
Driver protection
KbR
Transport length
2.39 m
Transport width
1.582 m
Transport height
1.948 m
Travel speed
12.6 km/h
Max. discharge height
2.379 m
Model series
R
Engine manuf.
Yanmar
Engine type
4TNV98C
Engine power
51 kW
Revolutions at max torque
2500 rpm
Max. torque
241.1 Nm
No. of cylinders
4
Emission level
Stage V

More technical details, like: weight, track width, bucket capacity, steering mode, lifting force, dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No
