256C Caterpillar 256C Specifications & Technical Data (2007—2026)

C-Series Skid Steer Loaders

The new Cat C-Series Skid Steer Loaders lead the industry in operator comfort, performance and versatility. Inside the spacious operator station, feel the superior comfort of a sealed and pressurized cab. Adjustable seat mounted controls and an available air ride seat keep you comfortable throughout the work day. Increased rated operating capacities, higher horsepower and improved drawbar performance help you get more done and increase your bottom line.

Two Speed Option

Two speed is available as an option on all C-Series Skid Steer Loaders to increase cycle times and get the job done faster.

High Flow XPS

High flow XPS hydraulic system is available on all models for greater machine versatility. Maximum performance can be maintained regardless of the work tool speed or conditions with this load sensing, pressure compensating system. Caterpillar cooling systems are sized to allow the operator to continuously power high flow work tools in conditions that cause competitive machines to overheat.

Speed Sensitive Ride Control

The optional Speed Sensitive Ride Control system delivers a smoother ride on uneven terrain for superior comfort. It allows for both higher speed operation and better material retention for increased productivity. The system automatically turns off when digging or placing a load for maximum performance and control.

Quick Couplers

Work tools can be changed quickly and easily with the Cat Skid Steer Loader’s quick coupler system. The standard quick coupler features manual engagement and disengagement of work tools using two high leverage handles. The optional hydraulic quick coupler allows the operator to quickly change tools without leaving the cab.

Cat Engine

The high performance power train provides high engine horsepower and torque. The C-Series features the Cat C3.4 DIT engine – a rugged, reliable engine that meets U.S. EPA Tier 3 emissions requirements. The Cat C3.4 DIT meets U.S. EPA Interim Tier 4 requirements on the 246C. The 272C is equipped with an Air-to-Air After Cooler (ATAAC) for better fuel efficiency and lower emissions as well as increased horsepower and torque.

Electronic Torque Management

The Electronic Torque Management system maximizes power to the ground and prevents the engine from stalling in tough digging and dozing applications for maximum productivity. The system allows part throttle operation which provides smoother machine operation and reduces fuel consumption.

High Performance Hydraulic System

Maximum power and reliability are built into the Cat Skid Steer Loader hydraulic system. In addition to providing power to the wheels, this system also powers the loader lift and tilt functions, powers the auxiliary circuit to drive work tools and drives the engine cooling fan. The C-Series hydraulic system features: Increased lift and tilt breakout forces allowing you to move more material and get more done. Continuous demand fan for improved fuel efficiency, increased horsepower, reduced sound levels and improved cold weather performance. Cat ToughGuard hoses for increased reliability and durability. High capacity hydraulic tank and side-by-side cooling package keep components cool for maximum durability.

Hand and Foot Throttles

Hand and foot throttles allow the operator to match engine speed to the task. The hand throttle is ideal for jobs requiring constant engine speed such as cold planing, trenching or snow blowing. The foot throttle lets the operator vary engine speed and minimize fuel consumption for other tasks such as load and carry, truck loading, grading and dozing.

Selectable Work Speed Control

The optional Selectable Work Speed Control lets you select the ground speed that is best suited for the application. This feature is useful in operations such as trenching and cold planing that require precise machine control at relatively slow and constant speeds.

Selectable Implement Control

The Selectable Implement Control option with three levels of control gives the operator the ability to adjust the responsiveness and speed of the lift and tilt functions for more precise implement control.

Easy Service

Convenient service features make maintenance easy, reducing your downtime: Rear door opens 90 degrees for easy access to both sides of the engine. Cooling package tilts up to provide excellent access to the engine compartment. Cab tilts rearward for easy access to all hydraulic pumps, motors, valves, lines and hydraulic tank. Daily maintenance points are easily accessible. Wires are color coded and numbered for easy identification. S•O•SSM oil sampling valves are standard to allow regular monitoring of the engine and hydraulic oil quality.
