TR370B Case TR370B Specifications & Technical Data (2020—2026)

The Case TR370B is a skid steer loader manufactured by Case since 2020. It has a weight of 4.22 tons and a transport length of 3.6…

The Case TR370B is a skid steer loader manufactured by Case since 2020. It has a weight of 4.22 tons and a transport length of 3.6 meters. The maximum discharge height is 2.67 meters, and it has a travel speed of 8.2 km/h. The transport width is 1.93 meters, and the transport height is 2.04 meters. The rated operating capacity is 1682 kilograms.

Skid Steer Loaders Case TR370B

Technical specs - TR370B Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.22 t
Rated operating capacity
1682 kg
Standard tyres
12.00x16.5 tyres
Transport length
3.6 m
Transport width
1.93 m
Transport height
2.04 m
Travel speed
8.2 km/h
Max. discharge height
2.67 m
Engine manuf.
FPT
Engine type
F5H
Engine power
55 kW
Displacement
3.4 l
Revolutions at max torque
1400 rpm
Max. torque
314 Nm
Emission level
V

More technical details, like: track width, bucket width, bucket capacity, driver protection, steering mode, lifting force, model series, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Case TR370B FAQ

When was the Case TR370B manufactured?

The Case TR370B was first produced in 2020.

How much does the Case TR370B skid steer loader weigh?

The Case TR370B skid steer loader weighs 4.22 tons.

What are the transport dimensions of the Case TR370B skid steer loader?

The Case TR370B has a transport length of 3.6 meters, a transport width of 1.93 meters, and a transport height of 2.04 meters.

What is the travel speed of the Case TR370B skid steer loader?

The Case TR370B skid steer loader has a travel speed of 8.2 km/h.

What are the undercarriage specifications of the Case TR370B skid steer loader?

The Case TR370B skid steer loader is equipped with standard 12.00x16.5 tyres.

What is the material handling capacity of the Case TR370B skid steer loader?

The Case TR370B skid steer loader has a rated operating capacity of 1682 kg and a maximum discharge height of 2.67 meters.

How much is a Case TR370B Skid steer loader (2020u20132025) worth?

The residual value of the Case TR370B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
