SV185B Case SV185B Specifications & Technical Data (2020—2026)

The Case SV185B is a skid steer loader manufactured by Case since 2020. It has a weight of 2.98 tons and a transport length of 3.3…

The Case SV185B is a skid steer loader manufactured by Case since 2020. It has a weight of 2.98 tons and a transport length of 3.345 meters. The maximum discharge height is 2.38 meters, and it has a travel speed of 11.9 km/h. The transport width is 1.678 meters, and the transport height is 1.974 meters. The lifting force is 24.7 kilonewtons, and the rated operating capacity is 840 kilograms.

Skid Steer Loaders Case SV185B
Skid Steer Loaders Case SV185B
Skid Steer Loaders Case SV185B
Skid Steer Loaders Case SV185B
Skid Steer Loaders Case SV185B
Skid Steer Loaders Case SV185B
Skid Steer Loaders Case SV185B
Skid Steer Loaders Case SV185B
Skid Steer Loaders Case SV185B
Skid Steer Loaders Case SV185B
Skid Steer Loaders Case SV185B
Skid Steer Loaders Case SV185B

Technical specs - SV185B Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.98 t
Rated operating capacity
840 kg
Standard tyres
10X16.5 Non-Pneumatic 64OTW
Transport length
3.345 m
Transport width
1.678 m
Transport height
1.974 m
Travel speed
11.9 km/h
Max. discharge height
2.38 m
Lifting force
24.7 kN
Engine manuf.
ISM
Engine type
N844 LTA-DI-F
Engine power
45 kW
Displacement
2.2 l
Revolutions at max torque
1800 rpm
Max. torque
183 Nm
Emission level
V

More technical details, like: track width, bucket width, bucket capacity, driver protection, steering mode, model series, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Case SV185B FAQ

When was the Case SV185B manufactured?

The Case SV185B was first produced in 2020.

How much does the Case SV185B skid steer loader weigh?

The Case SV185B skid steer loader weighs 2.98 tons.

What are the transport dimensions of the Case SV185B skid steer loader?

The Case SV185B has a transport length of 3.35 meters, a transport width of 1.68 meters, and a transport height of 1.97 meters.

What is the travel speed of the Case SV185B skid steer loader?

The Case SV185B skid steer loader has a travel speed of 11.9 km/h.

What are the standard tyres of the Case SV185B skid steer loader?

The Case SV185B skid steer loader has standard 10X16.5 Non-Pneumatic 64OTW tyres.

What is the power rating of the Case SV185B skid steer loader?

The source data does not provide a power rating for the Case SV185B skid steer loader.

What is the material handling capacity of the Case SV185B skid steer loader?

The Case SV185B skid steer loader has a rated operating capacity of 840 kg and a maximum discharge height of 2.38 meters.

How much is a Case SV185B Skid steer loader (2020u20132025) worth?

The residual value of the Case SV185B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
