Case SR 175 Specifications & Technical Data (2009-2015)

Rate this machine now!

The Case SR 175 is a skid steer loader manufactured by Case from 2009 to 2015. It has a weight of 2.81 tons and a transport length... Read more

The Case SR 175 is a skid steer loader manufactured by Case from 2009 to 2015. It has a weight of 2.81 tons and a transport length of 2.68 meters. With a travel speed of 19 km/h, it has a transport height of 1.97 meters. The rated operating capacity of this construction machine is 790 kilograms.

Technical specs - SR 175 Case


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 2.81 t
  • Rated operating capacity 790 kg
  • Transport length 2.68 m
  • Transport height 1.97 m
  • Travel speed 19 km/h
  • Engine manuf. ISM
  • Engine type 422 T-M3
  • Engine power 50 kW
  • Displacement 2.2 l
  • Revolutions at max torque 2900 rpm

More technical details, like: track width, standard tyres, bucket width, bucket capacity, driver protection, steering mode, transport width, max. discharge height, lifting force, model series, dimension lxwxh, max. torque...

Show more

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

  • Diesel particulate filter
  • LPG motor
  • Burglar proof system
