85 XT Case 85 XT Specifications & Technical Data (1998—2005)

Model rating
8,00 / 10

The Case 85 XT is a skid steer loader manufactured by Case from 1998 to 2005. It has a weight of 3.2 tons and a transport length o…

The Case 85 XT is a skid steer loader manufactured by Case from 1998 to 2005. It has a weight of 3.2 tons and a transport length of 3.44 meters. The bucket capacity is 0.48 cubic meters, with a bucket width of 1.85 meters. The maximum discharge height is 2.29 meters. The transport width is 1.83 meters, and the transport height is 2.03 meters. The lifting force is 27.4 kilonewtons, and the rated operating capacity is 1088 kilograms.

Skid Steer Loaders Case 85 XT

Technical specs - 85 XT Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.2 t
Rated operating capacity
1088 kg
Standard tyres
12.00-16.5
Bucket width
1.85 m
Bucket capacity
0.48 m³
Driver protection
KbR
Transport length
3.44 m
Transport width
1.83 m
Transport height
2.03 m
Travel speed
13.5 km/h
Max. discharge height
2.29 m
Lifting force
27.4 kN
Model series
XT
Engine manuf.
Case
Engine type
4-390
Engine power
56 kW
Displacement
3.19 l
Revolutions at max torque
2200 rpm

More technical details, like: track width, steering mode, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine manufacturer, engine model, aspiration...

More technical details, like: track width, steering mode, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine manufacturer, engine model, aspiration, rated speed, engine output - net, engine output - gross, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, heaped capacity, tipping load, operating capacity, speed - maximum, breakout - lift, breakout - bucket, pump type, pump flow, system pressure, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Case 85 XT FAQ

When was the Case 85 XT manufactured?

The Case 85 XT was manufactured from 1998 to 2005.

How much does the Case 85 XT skid steer loader weigh?

The Case 85 XT skid steer loader weighs 3.2 tons.

What are the transport dimensions of the Case 85 XT skid steer loader?

The Case 85 XT skid steer loader has a transport length of 3.44 meters, a transport width of 1.83 meters, and a transport height of 2.03 meters.

What is the travel speed of the Case 85 XT skid steer loader?

The Case 85 XT skid steer loader has a travel speed of 13.5 km/h.

What is the standard tyre size of the Case 85 XT skid steer loader?

The Case 85 XT skid steer loader is equipped with standard tyres sized 12.00-16.5.

What is the power rating of the Case 85 XT skid steer loader?

The source data does not provide a power rating for the Case 85 XT skid steer loader. However, it has a lifting force of 27.4 kN.

What is the material handling capacity of the Case 85 XT skid steer loader?

The Case 85 XT skid steer loader has a rated operating capacity of 1088 kg and a maximum discharge height of 2.29 meters.

What are the specifications of the primary work tool bucket on the Case 85 XT skid steer loader?

The Case 85 XT skid steer loader has a bucket with a capacity of 0.48 cubic meters and a width of 1.85 meters.

What operator safety features does the Case 85 XT skid steer loader have?

The Case 85 XT skid steer loader is equipped with a cabin that includes ROPS (Roll-Over Protective Structure) for driver protection.
