445 S 3 Case 445 S 3 Specifications & Technical Data (2008—2012)

The Case 445 S 3 is a skid steer loader manufactured by Case from 2008 to 2012. It has a weight of 3.68 tons and a transport lengt…

The Case 445 S 3 is a skid steer loader manufactured by Case from 2008 to 2012. It has a weight of 3.68 tons and a transport length of 3.44 meters. The bucket capacity is 0.54 cubic meters, with a bucket width of 2.13 meters. The maximum discharge height is 2.37 meters, and it has a travel speed of 18 km/h. The transport width is 1.9 meters, and the transport height is 2.03 meters. The lifting force is 32.9 kilonewtons, and the rated operating capacity is 1134 kilograms.

Skid Steer Loaders Case 445 S 3

Technical specs - 445 S 3 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.68 t
Rated operating capacity
1134 kg
Standard tyres
12x16.5
Bucket width
2.13 m
Bucket capacity
0.54 m³
Driver protection
KbR
Steering mode
AL
Transport length
3.44 m
Transport width
1.9 m
Transport height
2.03 m
Travel speed
18 km/h
Max. discharge height
2.37 m
Lifting force
32.9 kN
Model series
S
Engine manuf.
Case
Engine type
432T-M3
Engine power
61 kW
Displacement
3.2 l
Revolutions at max torque
2300 rpm

More technical details, like: track width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine manufacturer, engine model, emission rating, aspiration...

More technical details, like: track width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, engine output - gross, torque, transmission type, drive chain rating [ansi], tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, lift height, turning radius - rear corner, turning radius - bucket corner, fuel tank, heaped capacity, tipping load, operating capacity, speed - maximum, breakout - lift, breakout - bucket, pump type, hydraulic power, hydraulic power - option, pump flow, system pressure, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Case 445 S 3 FAQ

When was the Case 445 S 3 manufactured?

The Case 445 S 3 was manufactured from 2008 to 2012.

How much does the Case 445 S 3 skid steer loader weigh?

The Case 445 S 3 skid steer loader weighs 3.68 tons.

What are the transport dimensions of the Case 445 S 3 skid steer loader?

The Case 445 S 3 skid steer loader has a transport length of 3.44 meters, a transport width of 1.9 meters, and a transport height of 2.03 meters.

What is the travel speed of the Case 445 S 3 skid steer loader?

The Case 445 S 3 skid steer loader has a travel speed of 18 km/h.

What are the standard undercarriage specifications of the Case 445 S 3 skid steer loader?

The Case 445 S 3 skid steer loader has standard tyres sized 12x16.5.

What is the steering mode of the Case 445 S 3 skid steer loader?

The Case 445 S 3 skid steer loader has all-wheel steering.

What is the lifting force of the Case 445 S 3 skid steer loader?

The Case 445 S 3 skid steer loader has a lifting force of 32.9 kN.

What is the material handling capacity of the Case 445 S 3 skid steer loader?

The Case 445 S 3 skid steer loader has a rated operating capacity of 1134 kg and a maximum discharge height of 2.37 meters.

What are the specifications of the primary work tool bucket on the Case 445 S 3 skid steer loader?

The primary work tool bucket of the Case 445 S 3 skid steer loader has a capacity of 0.54 cubic meters and a width of 2.13 meters.

What operator safety and support features does the Case 445 S 3 skid steer loader have?

The Case 445 S 3 skid steer loader features a cabin with ROPS for driver protection.

How much is a Case 445 S 3 Skid steer loader (2008u20132012) worth?

The residual value of the Case 445 S 3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
