435 Case 435 Specifications & Technical Data (2005—2008)

The Case 435 is a skid steer loader manufactured by Case from 2005 to 2008. It has a weight of 3.14 tons and a transport length of…

The Case 435 is a skid steer loader manufactured by Case from 2005 to 2008. It has a weight of 3.14 tons and a transport length of 3.44 meters. The bucket capacity is 0.48 cubic meters, with a transport width of 1.9 meters and a transport height of 2.03 meters. The rated operating capacity of this construction machine is 1043 kilograms.

Skid Steer Loaders Case 435

Technical specs - 435 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.14 t
Rated operating capacity
1043 kg
Standard tyres
12x16.5
Bucket capacity
0.48 m³
Driver protection
Ü
Steering mode
AL
Transport length
3.44 m
Transport width
1.9 m
Transport height
2.03 m
Travel speed
17.7 km/h
Engine manuf.
Case
Engine type
334T-M2
Engine power
58 kW

More technical details, like: track width, bucket width, max. discharge height, lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level...

More technical details, like: track width, bucket width, max. discharge height, lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine manufacturer, engine model, aspiration, rated speed, engine output - net, engine output - gross, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, tipping load, operating capacity, speed - maximum, breakout - bucket, lift capacity, pump type, pump flow, system pressure, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Case 435 FAQ

When was the Case 435 skid steer loader manufactured?

The Case 435 skid steer loader was manufactured from 2005 to 2008.

How much does the Case 435 skid steer loader weigh?

The Case 435 skid steer loader weighs 3.14 tons.

What are the transport dimensions of the Case 435 skid steer loader?

The Case 435 skid steer loader has a transport length of 3.44 meters, a transport width of 1.9 meters, and a transport height of 2.03 meters.

What is the travel speed of the Case 435 skid steer loader?

The Case 435 skid steer loader has a travel speed of 17.7 km/h.

What is the standard tyre size of the Case 435 skid steer loader?

The standard tyre size of the Case 435 skid steer loader is 12x16.5.

What is the steering mode of the Case 435 skid steer loader?

The Case 435 skid steer loader features all-wheel steering.

What is the rated operating capacity of the Case 435 skid steer loader?

The Case 435 skid steer loader has a rated operating capacity of 1043 kilograms.

What is the bucket capacity of the Case 435 skid steer loader?

The Case 435 skid steer loader has a bucket capacity of 0.48 cubic meters.

What operator safety features does the Case 435 skid steer loader have?

The Case 435 skid steer loader is equipped with a roll-over bar for driver protection.
