T770 Bobcat T770 Specifications & Technical Data (2011—2017)

The Bobcat T770 is a skid steer loader manufactured by Bobcat from 2011 to 2017. It has a weight of 4.24 tons and a transport leng…

The Bobcat T770 is a skid steer loader manufactured by Bobcat from 2011 to 2017. It has a weight of 4.24 tons and a transport length of 3.63 meters. The bucket capacity is 1.4 cubic meters with a width of 2.03 meters. The maximum discharge height is 3.27 meters. The transport width and height are both 2.05 meters. It has a lifting force of 26.7 kilonewtons and a track width of 450 millimeters. The rated operating capacity is 1611 kilograms.

Visit Bobcat live at

T770

Years of manufacture: 2011—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - T770 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.24 t

Rated operating capacity: 1611 kg

Track width: 450 mm

Bucket width: 2.03 m

Bucket capacity: 1.4 m³

Driver protection: Kb

Transport length: 3.63 m

Transport width: 2.05 m

Transport height: 2.05 m

Travel speed: 10.6 km/h

Max. discharge height: 3.27 m

Lifting force: 26.7 kN

Model series: T

Engine manuf.: Kubota

Engine type: V3300-DI-T

Engine power: 58 kW

Displacement: 3.32 l

Revolutions at max torque: 2400 rpm

More technical details, like: standard tyres, steering mode, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, undercarriage type, lift geometry, access, suspension seat, telematics available, security system available, engine manufacturer, engine model, number of cylinders, aspiration, rated speed, engine output - gross, rated speed - torque, torque, transmission type, drive method, track rollers, track shoe width, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, track length on ground, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - bucket corner, fuel tank, tipping load, operating capacity, ground bearing pressure, speed - maximum, hydraulic power, hydraulic power - option, pump flow, pump flow - option, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter: No
LPG motor: No
Burglar proof system: No

Download datasheets (PDF)

Bobcat T770 FAQ

When was the Bobcat T770 manufactured?

The Bobcat T770 was manufactured from 2011 to 2017.

How much does the Bobcat T770 skid steer loader weigh?

The Bobcat T770 skid steer loader weighs 4.24 tons.

What are the transport dimensions of the Bobcat T770 skid steer loader?

The Bobcat T770 has a transport length of 3.63 meters, a transport width of 2.05 meters, and a transport height of 2.05 meters.

What is the travel speed of the Bobcat T770 skid steer loader?

The Bobcat T770 has a travel speed of 10.6 km/h.

What is the track width of the Bobcat T770 skid steer loader?

The Bobcat T770 skid steer loader has a track width of 450 mm.

What is the lifting force of the Bobcat T770?

The Bobcat T770 has a lifting force of 26.7 kN.

What is the material handling capacity of the Bobcat T770 skid steer loader?

The Bobcat T770 has a rated operating capacity of 1611 kg and a maximum discharge height of 3.27 meters.

What are the specifications of the primary work tool bucket on the Bobcat T770?

The Bobcat T770's primary work tool bucket has a capacity of 1.4 cubic meters and a width of 2.03 meters.

What operator safety features does the Bobcat T770 have?

The Bobcat T770 has a cabin for driver protection.

How much is a Bobcat T770 Skid steer loader (2011u20132017) worth?

The residual value of the Bobcat T770 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
