S650 Bobcat S650 Specifications & Technical Data (2010—2017)

Model rating
9,00 / 10

The Bobcat S650 is a skid steer loader manufactured by Bobcat from 2010 to 2017. It has a weight of 3.78 tons and a transport leng…

The Bobcat S650 is a skid steer loader manufactured by Bobcat from 2010 to 2017. It has a weight of 3.78 tons and a transport length of 3.47 meters. The bucket capacity is 0.91 cubic meters with a width of 1.88 meters. The maximum discharge height is 2.45 meters. The transport width is 1.83 meters and the transport height is 2.06 meters. It has a rated operating capacity of 1253 kilograms.

Skid Steer Loaders Bobcat S650
Skid Steer Loaders Bobcat S650
Skid Steer Loaders Bobcat S650
Skid Steer Loaders Bobcat S650
Skid Steer Loaders Bobcat S650
Skid Steer Loaders Bobcat S650
Skid Steer Loaders Bobcat S650
Skid Steer Loaders Bobcat S650
Skid Steer Loaders Bobcat S650
Skid Steer Loaders Bobcat S650

Visit Bobcat live at

Technical specs - S650 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.78 t
Rated operating capacity
1253 kg
Standard tyres
12.00-16.5 12 PR
Bucket width
1.88 m
Bucket capacity
0.91 m³
Driver protection
KbR
Transport length
3.47 m
Transport width
1.83 m
Transport height
2.06 m
Travel speed
11.4 km/h
Max. discharge height
2.45 m
Model series
S
Engine manuf.
Kubota
Engine type
V3307DI-T-E
Engine power
55.4 kW
Displacement
3.331 l
Revolutions at max torque
1600 rpm
Emission level
III B

More technical details, like: track width, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, lift geometry, access, rating standard - rops, rating standard - fops, telematics available...

More technical details, like: track width, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, engine manufacturer, engine model, aspiration, rated speed, engine output - gross, torque, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, lift height, turning radius - bucket corner, fuel tank, tipping load, operating capacity, speed - maximum, hydraulic power, hydraulic power - option, pump flow, system pressure, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Click and see the specifications of Bobcat S650 in the PDF

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Bobcat S650 FAQ

When was the Bobcat S650 manufactured?

The Bobcat S650 was manufactured from 2010 to 2017.

How much does the Bobcat S650 skid steer loader weigh?

The Bobcat S650 skid steer loader weighs 3.78 tons.

What are the transport dimensions of the Bobcat S650 skid steer loader?

The Bobcat S650 has a transport length of 3.47 meters, a transport width of 1.83 meters, and a transport height of 2.06 meters.

What is the travel speed of the Bobcat S650 skid steer loader?

The Bobcat S650 has a travel speed of 11.4 km/h.

What are the undercarriage tyre specifications of the Bobcat S650 skid steer loader?

The Bobcat S650 skid steer loader is equipped with standard tyres sized 12.00-16.5 12 PR.

What is the material handling capacity of the Bobcat S650 skid steer loader?

The Bobcat S650 has a rated operating capacity of 1253 kg and a maximum discharge height of 2.45 meters.

What are the bucket specifications of the Bobcat S650 skid steer loader?

The Bobcat S650 skid steer loader has a bucket capacity of 0.91 cubic meters and a bucket width of 1.88 meters.

What operator safety and support features does the Bobcat S650 have?

The Bobcat S650 is equipped with a cabin that includes ROPS (Roll Over Protective Structure) for driver protection.

How much is a Bobcat S650 Skid steer loader (2010u20132017) worth?

The residual value of the Bobcat S650 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
