S630 Bobcat S630 Specifications & Technical Data (2010—2017)

Model rating
9,00 / 10

The Bobcat S630 is a skid steer loader manufactured by Bobcat from 2010 to 2017. It has a weight of 3.5 tons and a transport lengt…

The Bobcat S630 is a skid steer loader manufactured by Bobcat from 2010 to 2017. It has a weight of 3.5 tons and a transport length of 3.47 meters. The bucket capacity is 0.91 cubic meters with a width of 1.88 meters. The maximum discharge height is 2.37 meters. The transport width is 1.83 meters and the transport height is 2.06 meters. It has a rated operating capacity of 1040 kilograms.

Skid Steer Loaders Bobcat S630
Skid Steer Loaders Bobcat S630
Skid Steer Loaders Bobcat S630
Skid Steer Loaders Bobcat S630
Skid Steer Loaders Bobcat S630
Skid Steer Loaders Bobcat S630
Skid Steer Loaders Bobcat S630
Skid Steer Loaders Bobcat S630
Skid Steer Loaders Bobcat S630
Skid Steer Loaders Bobcat S630

Visit Bobcat live at

Technical specs - S630 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.5 t
Rated operating capacity
1040 kg
Standard tyres
12.00-16.5 12PR
Bucket width
1.88 m
Bucket capacity
0.91 m³
Driver protection
KbR
Transport length
3.47 m
Transport width
1.83 m
Transport height
2.06 m
Travel speed
11.4 km/h
Max. discharge height
2.37 m
Model series
S
Engine manuf.
Kubota
Engine type
V3307DI-T-E
Engine power
54 kW
Displacement
3.331 l
Revolutions at max torque
1600 rpm

More technical details, like: track width, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, rating standard - rops, rating standard - fops...

More technical details, like: track width, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, engine manufacturer, engine model, aspiration, rated speed, engine output - gross, torque, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, lift height, turning radius - bucket corner, fuel tank, tipping load, operating capacity, speed - maximum, hydraulic power, hydraulic power - option, pump flow, system pressure, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Bobcat S630 FAQ

When was the Bobcat S630 manufactured?

The Bobcat S630 was manufactured from 2010 to 2017.

How much does the Bobcat S630 weigh?

The Bobcat S630 weighs 3.5 tons.

What are the transport dimensions of the Bobcat S630 skid steer loader?

The Bobcat S630 has a transport length of 3.47 meters, a transport width of 1.83 meters, and a transport height of 2.06 meters.

What is the travel speed of the Bobcat S630 skid steer loader?

The Bobcat S630 has a travel speed of 11.4 km/h.

What are the undercarriage specifications of the Bobcat S630 skid steer loader?

The Bobcat S630 skid steer loader comes equipped with standard tyres sized 12.00-16.5 12PR.

What is the material handling capacity of the Bobcat S630 skid steer loader?

The Bobcat S630 has a rated operating capacity of 1040 kg and a maximum discharge height of 2.37 meters.

What are the specifications of the primary work tool on the Bobcat S630 skid steer loader?

The Bobcat S630 skid steer loader has a bucket with a capacity of 0.91 cubic meters and a width of 1.88 meters.

What operator safety and support features does the Bobcat S630 have?

The Bobcat S630 is equipped with a cabin that includes ROPS for driver protection.

How much is a Bobcat S630 Skid steer loader (2010u20132017) worth?

The residual value of the Bobcat S630 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
