Technical specs - S570 Bobcat
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 2.94 t
- Rated operating capacity
- 942 kg
- Standard tyres
- 10x16.5 10–ply.
- Bucket width
- 1.73 m
- Bucket capacity
- 0.93 m³
- Driver protection
- KbR
- Steering mode
- AL
- Transport length
- 3.38 m
- Transport width
- 1.73 m
- Transport height
- 1.97 m
- Travel speed
- 17.3 km/h
- Max. discharge height
- 2.32 m
- Model series
- S
- Engine manuf.
- Bobcat
- Engine type
- D24
- Engine power
- 42.5 kW
- Displacement
- 2.392 l
- Revolutions at max torque
- 1800 rpm
- Max. torque
- 205 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 90x94 mm
- Emission level
- IIIB
More technical details, like: track width, lifting force, dimension lxwxh are available in the full technical specs.
Basic model with ROPS cabin and std. shovel with teeth
Special equipment
- Diesel particulate filter
-
No
- LPG motor
-
No
- Burglar proof system
-
No
Download datasheets (PDF)
