S570 Bobcat S570 Specifications & Technical Data (2013—2017)

The Bobcat S570 is a skid steer loader manufactured by Bobcat from 2013 to 2017. It has a weight of 2.9 tons and a transport lengt…

The Bobcat S570 is a skid steer loader manufactured by Bobcat from 2013 to 2017. It has a weight of 2.9 tons and a transport length of 3.38 meters. The bucket capacity is 0.93 cubic meters with a width of 1.727 meters. The maximum discharge height is 2.32 meters. The transport width is 1.64 meters and the transport height is 1.97 meters. The rated operating capacity is 944 kilograms.

Visit Bobcat live at

S570

Years of manufacture: 2013—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - S570 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.9 t

Rated operating capacity: 944 kg

Standard tyres: 10.00-16.5 10 PR

Bucket width: 1.727 m

Bucket capacity: 0.93 m³

Driver protection: KbR

Transport length: 3.38 m

Transport width: 1.64 m

Transport height: 1.97 m

Travel speed: 11.8 km/h

Max. discharge height: 2.32 m

Model series: S

Engine manuf.: Kubota

Engine type: V2607DI-T-E

Engine power: 45.5 kW

Displacement: 2.6 l

Revolutions at max torque: 1425 rpm

Emission level: III B

More technical details, like: track width, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, engine manufacturer, engine model, aspiration, rated speed, engine output - gross, torque, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, lift height, turning radius - bucket corner, fuel tank, tipping load, operating capacity, speed - maximum, hydraulic power, hydraulic power - option, pump flow, system pressure, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter: No
LPG motor: No
Burglar proof system: No

Download datasheets (PDF)

Bobcat S570 FAQ

When was the Bobcat S570 manufactured?

The Bobcat S570 was manufactured from 2013 to 2017.

How much does the Bobcat S570 weigh?

The Bobcat S570 weighs 2.9 tons.

What are the transport dimensions of the Bobcat S570 skid steer loader?

The Bobcat S570 has a transport length of 3.38 meters, a transport width of 1.64 meters, and a transport height of 1.97 meters.

What is the travel speed of the Bobcat S570 skid steer loader?

The Bobcat S570 has a travel speed of 11.8 km/h.

What are the standard tyres specifications of the Bobcat S570 skid steer loader?

The Bobcat S570 skid steer loader is equipped with standard tyres sized 10.00-16.5 10 PR.

What is the material handling capacity of the Bobcat S570 skid steer loader?

The Bobcat S570 has a rated operating capacity of 944 kg and a maximum discharge height of 2.32 meters.

What are the specifications of the primary work tool bucket on the Bobcat S570?

The Bobcat S570 has a bucket with a capacity of 0.93 cubic meters and a width of 1.73 meters.

What operator safety and support features does the Bobcat S570 have?

The Bobcat S570 features a cabin with ROPS for driver protection.

How much is a Bobcat S570 Skid steer loader (2013u20132017) worth?

The residual value of the Bobcat S570 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
