Technical specs - ViO23-6 Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.405 t
Transport length
4.27 m
Transport width
1.55 m
Transport height
2.48 m
Track width
250 mm
Driver protection
Kb
Max. Reach horizontal
4.22 m
Dredging depth
2.655 m
Tear-out force
17.5 kN
Model series
ViO
Engine manuf.
Yanmar
Engine type
3TNV76-PBV1
Engine power
14.3 kW
Displacement
1.11 l
Revolutions at max torque
2400 rpm
Max. torque
68,6/1800 Nm
No. of cylinders
3
Emission level
V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Yanmar ViO23-6 FAQ

When was the Yanmar ViO 23-6 manufactured?

The Yanmar ViO 23-6 was first produced in 2024.

How much does the Yanmar ViO 23-6 weigh?

The Yanmar ViO 23-6 weighs 2.405 tons.

What are the transport dimensions of the Yanmar ViO 23-6 mini excavator?

The Yanmar ViO 23-6 has a transport length of 4.27 meters, a transport width of 1.55 meters, and a transport height of 2.48 meters.

What is the track width of the Yanmar ViO 23-6 mini excavator?

The Yanmar ViO 23-6 mini excavator has a track width of 250 mm.

What are the excavation performance specifications of the Yanmar ViO 23-6 mini excavator?

The Yanmar ViO 23-6 mini excavator has a dredging depth of 2.655 meters and a maximum horizontal reach of 4.22 meters.

What is the tear-out force of the Yanmar ViO 23-6 mini excavator?

The Yanmar ViO 23-6 mini excavator has a tear-out force of 17.5 kN.

What operator safety features does the Yanmar ViO 23-6 have?

The Yanmar ViO 23-6 has driver protection in the form of a cabin.
