SV19VT Yanmar excavator specs & dimensions (2021 - 2026)

Yanmar SV19VT is a mini excavator manufactured since 2021, with a weight of 1.84 tons. It has a transport length of 3.62 meters, a…

Yanmar SV19VT is a mini excavator manufactured since 2021, with a weight of 1.84 tons. It has a transport length of 3.62 meters, a transport width of 1.32 meters, and a transport height of 2.33 meters.

SV19VT

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - SV19VT Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.88 t

Transport length: 4.205 m

Transport width: 1.32 m

Transport height: 2.32 m

Track width: 230 mm

Driver protection: FD

Max. Reach horizontal: 4.135 m

Dredging depth: 2.885 m

Tear-out force: 16.7 kN

Model series: SV

Engine manuf.: Yanmar

Engine type: 3TNV76-QBVA

Engine power: 13.1 kW

Displacement: 1.116 l

Revolutions at max torque: 2100 rpm

Max. torque: 69,2/1600 Nm

No. of cylinders: 3

Emission level: V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: Yes
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Yanmar SV19VT FAQ

When was the Yanmar SV19VT manufactured?

The Yanmar SV19VT was first produced in 2021.

How much does the Yanmar SV19VT mini excavator weigh?

The Yanmar SV19VT mini excavator weighs 1.88 tons.

What are the transport dimensions of the Yanmar SV19VT mini excavator?

The Yanmar SV19VT has a transport length of 4.205 meters, a transport width of 1.32 meters, and a transport height of 2.32 meters.

What is the track width of the Yanmar SV19VT mini excavator?

The Yanmar SV19VT mini excavator has a track width of 230 mm.

What is the excavation performance of the Yanmar SV19VT mini excavator?

The Yanmar SV19VT has a dredging depth of 2.885 meters and a maximum horizontal reach of 4.135 meters.

What is the tear-out force of the Yanmar SV19VT mini excavator, and is its power rating provided?

The source data for the Yanmar SV19VT mini excavator does not provide power ratings. However, it has a tear-out force of 16.7 kN.

What operator safety and support features does the Yanmar SV19VT have?

The Yanmar SV19VT is equipped with a canopy for driver protection.

How much is a Yanmar SV19VT Mini excavator (2021u20132025) worth?

The residual value of the Yanmar SV19VT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
