SV 26 PR Yanmar excavator specs & dimensions (2013 - 2024)

Yanmar SV 26 PR is a mini excavator manufactured since 2013. It has a weight of 2.6 tons and a track width of 300 mm. The transpor…

Yanmar SV 26 PR is a mini excavator manufactured since 2013. It has a weight of 2.6 tons and a track width of 300 mm. The transport dimensions are 4.25 meters in length, 1.55 meters in width, and 2.435 meters in height. The machine features a tear-out force of 14.5 kN, a dredging depth of 2.995 meters, and a maximum horizontal reach of 4.51 meters. Special equipment includes a blade, hydraulic quick hitch, mechanical quick hitch, and rubber tracks.

Mini Excavators Yanmar SV 26 PR

Technical specs - SV 26 PR Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.6 t
Transport length
4.25 m
Transport width
1.55 m
Transport height
2.435 m
Track width
300 mm
Driver protection
FD
Max. Reach horizontal
4.51 m
Dredging depth
2.995 m
Tear-out force
14.5 kN
Model series
SV
Engine manuf.
Yanmar
Engine type
3TNV82A-BPBVA
Engine power
17.6 kW
Displacement
1.331 l
Revolutions at max torque
1400 rpm

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

Yanmar SV 26 PR FAQ

When was the Yanmar SV 26 PR manufactured?

The Yanmar SV 26 PR was manufactured from 2013 to 2024.

How much does the Yanmar SV 26 PR weigh?

The Yanmar SV 26 PR weighs 2.6 tons.

What are the transport dimensions of the Yanmar SV 26 PR mini excavator?

The Yanmar SV 26 PR has a transport length of 4.25 meters, a transport width of 1.55 meters, and a transport height of 2.44 meters.

What is the track width of the Yanmar SV 26 PR mini excavator?

The Yanmar SV 26 PR mini excavator has a track width of 300 mm.

What are the excavation specifications of the Yanmar SV 26 PR mini excavator?

The Yanmar SV 26 PR has a dredging depth of 2.995 meters and a maximum horizontal reach of 4.51 meters.

What is the power rating of the Yanmar SV 26 PR mini excavator?

The source data does not provide a power rating for the Yanmar SV 26 PR mini excavator.

What operator safety and support features does the Yanmar SV 26 PR have?

The Yanmar SV 26 PR is equipped with a canopy for driver protection.

How much is a Yanmar SV 26 PR Mini excavator (2013u20132024) worth?

The residual value of the Yanmar SV 26 PR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
