Technical specs - ECR40 Volvo
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.985 t
- Transport length
- 4.68 m
- Transport width
- 1.78 m
- Transport height
- 2.458 m
- Track width
- 300 mm
- Driver protection
- Kb
- Max. Reach horizontal
- 5.473 m
- Dredging depth
- 3.436 m
- Tear-out force
- 35.5 kN
- Model series
- ECR
- Engine manuf.
- Volvo
- Engine type
- D1.7A
- Engine power
- 18.5 kW
- Displacement
- 1.647 l
- Revolutions at max torque
- 2200 rpm
- Max. torque
- 97/1500 Nm
- No. of cylinders
- 3
- Emission level
- V
More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model with standard bucket
Special equipment
- Track adjustment
-
No
- Rubber track
-
Yes
- Blade
-
Yes
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
Download datasheets (PDF)
Volvo ECR40 FAQ
How much does the Volvo ECR40 mini excavator weigh?
What are the transport dimensions of the Volvo ECR40 mini excavator?
What is the track width of the Volvo ECR40 mini excavator?
What are the dredging depth and maximum horizontal reach of the Volvo ECR40 mini excavator?
What is the tear-out force of the Volvo ECR40 mini excavator?
What operator safety and support features does the Volvo ECR40 have?
How much is a Volvo ECR40 Mini excavator (2024u20132025) worth?
