Technical specs - SWE35UF Sunward
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.75 t
- Transport length
- 4.89 m
- Transport width
- 1.7 m
- Transport height
- 2.56 m
- Bucket capacity
- 0.11 m³
- Track width
- 300 mm
- Driver protection
- Kb
- Max. Reach horizontal
- 5.575 m
- Dredging depth
- 3.32 m
- Tear-out force
- 31.8 kN
- Model series
- SWE
- Engine manuf.
- Kubota
- Engine type
- D1703
- Engine power
- 18.2 kW
- Displacement
- 1.647 l
- Revolutions at max torque
- 2200 rpm
- Max. torque
- 96/1500 Nm
- Emission level
- Euro V / US IV
More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with standard bucket
Special equipment
- Track adjustment
-
No
- Rubber track
-
Yes
- Blade
-
Yes
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
