SE75 Shantui excavator specs & dimensions (2020 - 2026)
Technical specs - SE75 Shantui
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 7.65 t
- Transport length
- 6.24 m
- Transport width
- 2.26 m
- Transport height
- 2.68 m
- Bucket capacity
- 0.32 m³
- Bucket capacity min.
- 0.25 m³
- Bucket capacity max.
- 0.35 m³
- Track width
- 450 mm
- Max. Reach horizontal
- 6.22 m
- Dredging depth
- 3.99 m
- Engine manuf.
- Kubota
- Engine type
- V3307T
- Engine power
- 48.9 kW
- Displacement
- 3.331 l
- No. of cylinders
- 4
- Cylinder bore x stroke
- 94x120 mm
- Emission level
- Tier 3 / Stage III
More technical details, like: bucket width, standard tyres, driver protection, tear-out force, model series, dimension lxwxh, revolutions at max torque, max. torque are available in the full technical specs.
Basic model with standard bucket
Special equipment
- Track adjustment
-
No
- Rubber track
-
No
- Blade
-
Yes
- Aircondition
-
Yes
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
Download datasheets (PDF)
Shantui SE75 FAQ
What are the transport dimensions of the Shantui SE75 mini excavator?
What is the track width of the Shantui SE75 mini excavator's undercarriage?
What is the excavation performance of the Shantui SE75 mini excavator?
What are the bucket capacity specifications of the Shantui SE75 mini excavator?
How much is a Shantui SE75 Mini excavator (2020u20132025) worth?
