904D Liugong excavator specs & dimensions (2017 - 2019)

Liugong 904D is a mini excavator manufactured from 2017 to 2019, with a weight of 4 tons. It features a track width of 300 mm, a t…

Liugong 904D is a mini excavator manufactured from 2017 to 2019, with a weight of 4 tons. It features a track width of 300 mm, a transport length of 5.15 meters, a transport width of 1.6 meters, and a transport height of 2.5 meters. The machine has a tear-out force of 28.3 kN, a dredging depth of 3.1 meters, and a maximum horizontal reach of 5.22 meters. The bucket capacity is 0.12 cubic meters.

Mini Excavators Liugong 904D

Visit Liugong live at

Technical specs - 904D Liugong

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4 t
Transport length
5.15 m
Transport width
1.6 m
Transport height
2.5 m
Bucket capacity
0.12 m³
Track width
300 mm
Max. Reach horizontal
5.22 m
Dredging depth
3.1 m
Tear-out force
28.3 kN
Model series
Compact
Engine manuf.
Yanmar
Engine type
4TNV88-BSBKC
Engine power
25.2 kW
Displacement
2.19 l
Revolutions at max torque
1320 rpm
Max. torque
142.1 Nm
No. of cylinders
4
Emission level
Tier 3 / Stage IIIA

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, driver protection, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liugong 904D FAQ

When was the Liugong 904D manufactured?

The Liugong 904D was manufactured from 2017 to 2019.

What is the weight of the Liugong 904D mini excavator?

The Liugong 904D mini excavator weighs 4 tons.

What are the transport dimensions of the Liugong 904D mini excavator?

The Liugong 904D has a transport length of 5.15 meters, a transport width of 1.6 meters, and a transport height of 2.5 meters.

What is the track width of the Liugong 904D mini excavator's undercarriage?

The Liugong 904D mini excavator has a track width of 300 mm.

What are the dredging depth and maximum horizontal reach of the Liugong 904D mini excavator?

The Liugong 904D mini excavator has a dredging depth of 3.1 meters and a maximum horizontal reach of 5.22 meters.

What is the tear-out force of the Liugong 904D mini excavator?

The Liugong 904D mini excavator has a tear-out force of 28.3 kN.

What is the bucket capacity of the Liugong 904D mini excavator?

The Liugong 904D mini excavator has a bucket capacity of 0.12 cubic meters.

How much is a Liugong 904D Mini excavator (2017u20132019) worth?

The residual value of the Liugong 904D depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
