E 35 SR Fiat Kobelco excavator specs & dimensions (2003 - 2005)

Fiat Kobelco E 35 SR is a mini excavator manufactured from 2003 to 2005. It has a weight of 3.62 tons and a track width of 300 mm.…

Fiat Kobelco E 35 SR is a mini excavator manufactured from 2003 to 2005. It has a weight of 3.62 tons and a track width of 300 mm. The transport dimensions are 4.72 meters in length, 1.7 meters in width, and 2.5 meters in height. The bucket capacity ranges from a minimum of 0.05 cubic meters to a maximum of 0.12 cubic meters. Special equipment includes a blade and rubber tracks.

Mini Excavators Fiat Kobelco E 35 SR

Technical specs - E 35 SR Fiat Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.62 t
Transport length
4.72 m
Transport width
1.7 m
Transport height
2.5 m
Bucket capacity min.
0.05 m³
Bucket capacity max.
0.12 m³
Track width
300 mm
Driver protection
Kb
Max. Reach horizontal
4.4 m
Dredging depth
3.11 m
Tear-out force
52.9 kN
Engine manuf.
Yanmar
Engine type
3TNE82A
Engine power
18 kW
Displacement
1.33 l
Revolutions at max torque
2400 rpm

More technical details, like: bucket capacity, bucket width, standard tyres, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Fiat Kobelco E 35 SR FAQ

When was the Fiat Kobelco E 35 SR manufactured?

The Fiat Kobelco E 35 SR was manufactured from 2003 to 2005.

How much does the Fiat Kobelco E 35 SR weigh?

The Fiat Kobelco E 35 SR weighs 3.62 tons.

What are the transport dimensions of the Fiat Kobelco E 35 SR mini excavator?

The Fiat Kobelco E 35 SR has a transport length of 4.72 meters, a transport width of 1.7 meters, and a transport height of 2.5 meters.

What is the track width of the undercarriage on the Fiat Kobelco E 35 SR mini excavator?

The Fiat Kobelco E 35 SR mini excavator has a track width of 300 mm.

What are the excavation performance specifications of the Fiat Kobelco E 35 SR?

The Fiat Kobelco E 35 SR has a dredging depth of 3.11 meters and a maximum horizontal reach of 4.4 meters.

What is the tear-out force of the Fiat Kobelco E 35 SR?

The Fiat Kobelco E 35 SR has a tear-out force of 52.9 kN.

What are the bucket capacity specifications of the Fiat Kobelco E 35 SR mini excavator?

The Fiat Kobelco E 35 SR mini excavator has a bucket capacity ranging from 0.05 to 0.12 cubic meters.

What operator safety features does the Fiat Kobelco E 35 SR have?

The Fiat Kobelco E 35 SR has a cabin for driver protection.

How much is a Fiat Kobelco E 35 SR Mini excavator (2003u20132005) worth?

The residual value of the Fiat Kobelco E 35 SR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
