304E CR Caterpillar excavator specs & dimensions (2012 - 2016)

Caterpillar 304E CR is a mini excavator manufactured from 2012 to 2016, with a weight of 4 tons. It features a track width of 350 …

Caterpillar 304E CR is a mini excavator manufactured from 2012 to 2016, with a weight of 4 tons. It features a track width of 350 mm, a transport length of 4.82 meters, a transport width of 1.95 meters, and a transport height of 2.5 meters. The bucket width is 0.3 meters with a bucket capacity of 0.054 cubic meters. Special equipment includes air conditioning and track adjustment.

Mini Excavators Caterpillar 304E CR
Mini Excavators Caterpillar 304E CR
Mini Excavators Caterpillar 304E CR
Mini Excavators Caterpillar 304E CR
Mini Excavators Caterpillar 304E CR
Mini Excavators Caterpillar 304E CR

Technical specs - 304E CR Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4 t
Transport length
4.82 m
Transport width
1.95 m
Transport height
2.5 m
Bucket capacity
0.054 m³
Bucket width
0.3 m
Track width
350 mm
Driver protection
Kb
Max. Reach horizontal
5.22 m
Dredging depth
3.13 m
Tear-out force
30.8 kN
Model series
CR
Engine manuf.
Caterpillar
Engine type
C2.4
Engine power
31 kW
Displacement
2.4 l
Cylinder bore x stroke
87x102 mm
Emission level
Tier 4 f

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
No
Blade
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download specalog and datasheets (PDF)

Caterpillar 304E CR FAQ

When was the Caterpillar 304E CR manufactured?

The Caterpillar 304E CR was manufactured from 2012 to 2016.

How much does the Caterpillar 304E CR weigh?

The Caterpillar 304E CR weighs 4 tons.

What are the transport dimensions of the Caterpillar 304E CR mini excavator?

The Caterpillar 304E CR has a transport length of 4.82 meters, a transport width of 1.95 meters, and a transport height of 2.5 meters.

What is the track width of the Caterpillar 304E CR's undercarriage?

The Caterpillar 304E CR has a track width of 350 mm.

What is the excavation performance of the Caterpillar 304E CR mini excavator?

The Caterpillar 304E CR mini excavator has a dredging depth of 3.13 meters and a maximum horizontal reach of 5.22 meters.

What is the tear-out force of the Caterpillar 304E CR mini excavator?

The Caterpillar 304E CR mini excavator has a tear-out force of 30.8 kN.

What are the specifications of the primary work tool bucket on the Caterpillar 304E CR mini excavator?

The primary work tool bucket of the Caterpillar 304E CR has a capacity of 0.054 cubic meters and a width of 0.3 meters.

What operator safety features does the Caterpillar 304E CR have?

The Caterpillar 304E CR has a cabin for driver protection.

How much is a Caterpillar 304E CR Mini excavator (2012u20132016) worth?

The residual value of the Caterpillar 304E CR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
