CZ37 Cams excavator specs & dimensions (2021 - 2026)

Cams CZ37 is a mini excavator manufactured since 2021, with a weight of 3.6 t and a track width of 300 mm. Its transport dimension…

Cams CZ37 is a mini excavator manufactured since 2021, with a weight of 3.6 t and a track width of 300 mm. Its transport dimensions are 2.95 m in length, 1.76 m in width, and 2.47 m in height. The dredging depth is 3.11 m, and it features a bucket width of 0.45 m with a capacity of 0.1 m³. Special equipment includes a blade and rubber track.

Mini Excavators Cams CZ37

Technical specs - CZ37 Cams

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.6 t
Transport length
2.95 m
Transport width
1.76 m
Transport height
2.47 m
Bucket capacity
0.1 m³
Bucket width
0.45 m
Track width
300 mm
Driver protection
Kb
Max. Reach horizontal
5.29 m
Dredging depth
3.11 m
Tear-out force
27.4 kN
Model series
CZ
Engine manuf.
Kubota
Engine type
M1503
Engine power
18.5 kW
Displacement
1.647 l
Revolutions at max torque
2200 rpm
No. of cylinders
3
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Cams CZ37 FAQ

When was the Cams CZ37 manufactured?

The Cams CZ37 was first produced in 2021.

How much does the Cams CZ37 mini excavator weigh?

The Cams CZ37 mini excavator weighs 3.6 tons.

What are the transport dimensions of the Cams CZ37 mini excavator?

The Cams CZ37 has a transport length of 2.95 meters, a transport width of 1.76 meters, and a transport height of 2.47 meters.

What is the track width of the undercarriage on the Cams CZ37 mini excavator?

The Cams CZ37 mini excavator has a track width of 300 mm on its undercarriage.

What are the excavation performance specifications of the Cams CZ37 mini excavator?

The Cams CZ37 mini excavator has a dredging depth of 3.11 meters and a maximum horizontal reach of 5.29 meters.

What is the tear-out force of the Cams CZ37 mini excavator?

The Cams CZ37 mini excavator has a tear-out force of 27.4 kN.

What are the bucket specifications of the Cams CZ37 mini excavator?

The Cams CZ37 mini excavator has a bucket capacity of 0.1 cubic meters and a bucket width of 0.45 meters.

What operator safety and support features does the Cams CZ37 have?

The Cams CZ37 has a cabin for driver protection.

How much is a Cams CZ37 Mini excavator (2021u20132025) worth?

The residual value of the Cams CZ37 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
